37206789937 37206789938 4722555610 Air Suspension Solenoid Valve Block Solenoid Kit Solenoid Coil

37206789937 37206789938 4722555610 Air Suspension Solenoid Valve Block Solenoid Kit Solenoid Coil

Solenoid Coil Working Principle:

By placing a solenoid valve coil over a ferromagnetic core (usually magnetic 430F stainless steel armature) the magnetic field generated causes the plunger to slide further up towards the magnetic field (into the coil) thus allowing an opening to be created. This in turn can be utilised to either to control direct acting solenoid valves, Assisted Lift Solenoid Valves or Servo/ Pressure Assisted solenoid valves.

Solenoid valve coils come in a huge range of sizes, voltages, IP protection levels, temperature ratings and power levels.

Care needs to be taken when replacing solenoid valve coils because all these factors must be considered.

Solenoid Coil Sizing.
When measuring a coil you need to measure accurately the internal diameter of the coil (as above). Some solenoid coils may be fitted with a top plate with a reduced diameter to aid secure fitment to the armature / core tube. Then the depth of the internal core needs to be measured. If this matches up you are at the first step of finding the right coil. Helpful hint - when buying solenoid valve coils try to replace according to brand.

Solenoid Coil Voltages.
Coils are manufactured for specific voltages, it is very rare that a coil will work on more than 1 voltage weather it be AC or DC. There are some instances of "Dual voltage coils" which can work on for example 12vDC or 24vAC, 48vDC or 24vAC but these are quite rare and this cannot be relied on to over come spares shortfall's.

Dimension of 37206789937 37206789938 4722555610 Solenoid Coil:

Technical Data:

​

Attention:
1. This air suspension compressor pump solenoid coil is made of high quality components.
2. Replaces the original air compressor solenoid coil of your car and equal the original quality.
3. Please double confirm the compatibility as well as the OEM number before purchasing.
4. Instruction is not included. Professional installation is recommended.

Application of 37206789937 37206789938 4722555610 Air Suspension Compressor Pump Solenoid Coil:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
