2" DMF/MF Series SBFEC Type Pulse Jet Valve Diaphragm Repair Kit​

2" DMF/MF Series SBFEC Type Pulse Jet Valve Diaphragm Repair Kit​

2" DMF/MF Series SBFEC Type Pulse Jet Valve Diaphragm Repair Kit​
video
2" DMF/MF Series SBFEC Type Pulse Jet Valve Diaphragm Repair Kit​
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D50
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 4-8 day Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Size: 2'' Air Hole: With
Spring: With Packaging: Individual Sealed
Diaphragm Material: Nitrile/Buna Suitable Valve Number: MF/DMF-Z-50S MF/DMF-Y-50S MF/DMF-ZM-50S
Diaphragm Outer Distance: 160mm Center Distance: 142mm
Seat OD: 75mm
High Light:

SBFEC Type Pulse Jet Valve

,

BFEC Membrane Rebuild Kit

,

Dust Collector Diaphragm Kit

2'' DMF/MF Series SBFEC Type Pulse Jet Valve Diaphragm Repair Kit​



Diaphragm repair kits for SBFEC 2'' diaphragm pulse valves (MF-Z-50S, DMF-Z-50S, MF-Y-50S, DMF-Y-50S, MF-T-50S, DMF-T-50S), used for reverse pulse jet bag filter dust collector. The following are some cautions:



1.Temperature:-10°C~55°C

2.The relative humidity of air not exceeding 85%

3. Service life of diaphragm:1 million times

4. Working pressure have to control from 0.2 to 0.6Mpa, and steadily.



Available Models of BFEC DMF/MF Series Diaphragm Repair Kit:



Ordering Code
Fitted Valve Code
Port Size
DTY
MF/DMF-T-25S, MF/DMF-T-40S, MF/DMF-T-50S, MF/DMF-T-62S,
MF/DMF-ZM-40S, MF/DMF-Y-40S, MF/DMF-Y-50S, MF/DMF-Y-62S,
MF/DMF-Y-76S, MF/DMF-YA-76S, MF/DMF-YB-76S, MF/DMF-Y-102S,
MF/DMF-Y-102SA, MF/DMF-Y-102SE, MF/DMF-ZF-40S, MF/DMF-Z-40S,
MF/DMF-Z-50S, MF/DMF-Z-62S, MF/DMF-Z-76S, MF/DMF-Z-102S
Secondary Diaphragm
D20A
DMF-Z-20, MF-Z-20, DMF-ZM-20, MF-ZM-20
3/4''
D25
DMF-Z-25, MF-Z-25, DMF-ZM-25, MF-ZM-25,
DMF-ZF-25, MF-ZF-25, DMF-Y-25, MF-Y-25,
DMF-T-20, MF-T-20
3/4'' & 1''
D40
DMF-Z-40S, MF-Z-40S, DMF-Y-40S, MF-Y-40S,
DMF-ZF-40S, MF-ZF-40S, DMF-ZM-40S, MF-ZM-40S,
DMF-T-25S, MF-T-25S
1'' & 1-1/2''
D50
DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S,
DMF-T-50S, MF-T-50S
2''
D62
DMF-Z-62S, MF-Z-62S, DMF-Y-62S, MF-Y-62S
2-1/2''
D76
DMF-Z-76S, MF-Z-76S, DMF-Y-76S, MF-Y-76S
3''
D102
DMF-Z-102S, MF-Z-102S, DMF-Y-102S, MF-Y-102S
4''
D102A
DMF-Y-102SA, MF-Y-102SA
4''
DZL-20B
DMF-ZL-B, MF-ZL-B
3/4''


Dimension Diagram:

2''  DMF/MF Series SBFEC Type Pulse Jet Valve Diaphragm Repair Kit Dimension



Diaphragm Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
*No leakage
*No Lubrication
* No Breakaway Force
* No Friction
* Functionality Over Wide Pressure Ranges
* High Strength
* Low Cost
* Simple Design
* Versatility
5. EPDM, FKM all available.



Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
