K2546 G1" TPE Material Diaphragm Repair Kit For RCAC25 T4 / DD4 / FS4 Solenoid Pulse Valve

K2546 G1" TPE Material Diaphragm Repair Kit For RCAC25 T4 / DD4 / FS4 Solenoid Pulse Valve

  • K2546 G1" TPE Material Diaphragm Repair Kit For RCAC25 T4 / DD4 / FS4 Solenoid Pulse Valve
  • K2546 G1" TPE Material Diaphragm Repair Kit For RCAC25 T4 / DD4 / FS4 Solenoid Pulse Valve
K2546 G1" TPE Material Diaphragm Repair Kit For RCAC25 T4 / DD4 / FS4 Solenoid Pulse Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: K2546
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 4-8 day Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Size: 1'' Air Hole: With
Spring: With Packaging: Individual Sealed
Diaphragm Material: Nitrile/Buna Suitable Valve Number: RCAC25T4, RCAC25DD4, RCAC25FS4
Diaphragm Outer Distance: 91mm Center Distance: 93mm
Seat OD: 46mm
High Light:

Goyen Diaphragm

,

Goyen Pulse Valve Diaphragm

,

Goyen Diaphragm Repair Kit

K2546 G1'' TPE Material Diaphragm Repair Kit For RCAC25 T4 / DD4 / FS4 Solenoid Pulse Valve



This is K2546 shockwave diaphragm kit, which is a springless diaphragm used in Goyen 1" RCAC25T4, RCAC25DD4, RCAC25FS4 diaphragm valves. The diaphragm is the key component in diaphragm pulse jet valves. It is one of the fittings for the normal operation of the valve body and the "switch" of the injection air circuit of the dust cleaning system of the pulse bag filter. It can easily ensure complete synchronization with other control components to control the injection of pulsed compressed air. So the tightness and softness of the diaphragm play a decisive role in the blowing effect of the pulse valve.





Goyen Type Diaphragm Repair Kit:





Deference number:

Material Repair kit Fitted Valve Model Port Size
Buna/Nylon K2000(M1204B) CA20, RCA20, RCAC20 3/4''
K2003(M1174B)
K2016
K2034
Buna/Buna K2002(M764)
FKM K2007(M2080B)
K2004(1328B)
K2017
K2033
Buna/Nylon K2501(M1183B) CA25, RCA25, RCAC25 1''
K2529
K2549
K2531
K2545
K2546
Buna/Buna K2502(M736)
FKM K2503(M1887)
K2530
K2532
K2551
Buna/Nylon K2500(M1183)
CA32, RCA32, CA35, RCA35,
CA40, RCA40, CA45, RCA45
1-1/2''
K3500(M1581)
K4000(M1182)
K4502(M2162)
Buna/Buna K3502(M1591)
K4504(M2187)
FKM K2503(M1887)
K4004(M1761)
K4007(M1156)
K4503(M2163)

Buna/Nylon

Buna/Buna

K5004(M1638A) CA50, RCA50, CA62, RCA62 2'' , 2-1/2''
K5005(M1639A)
FKM K5000(M1157A)
K5002(M1528A)

Buna/Nylon

Buna/Buna

K7600 CA76, RCA76 3''
K7604
K7610
FKM K7602
Buna/Nylon K10200 CA102, RCA102 4''
Buna/Buna K10203
FKM K10201

Buna/Nylon

Buna/Buna

K8000 CA8, RCA8 8''
FKM


Dimension Diagram:

K2546 G1'' TPE Material Diaphragm Repair Kit For RCAC25 T4 / DD4 / FS4 Solenoid Pulse Valve DIMENSION



Diaphragm Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
*No leakage
*No Lubrication
* No Breakaway Force
* No Friction
* Functionality Over Wide Pressure Ranges
* High Strength
* Low Cost
* Simple Design
* Versatility
5. EPDM, FKM all available.



Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
