18 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve

18 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve

18 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve
video
18 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BPV10
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Application: Steam Iron, Cleaning Machine, Coffee Macchine, RO System Temperature: -10℃~+80℃
Power: Solenoid Media: Water, Air, Oil
Structure: Plunger Operation: Direct Acting
Seal Material: NBR, FKM, EPDM Voltage: DC12V DC24V AC24V AC120V AC240V
Port: NPT1/4''
High Light:

Diaphragm Plastic Solenoid Valve

,

Direct Acting Latching Solenoid Valve

,

Normally Closed Solenoid Valve

18 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve


RO water solenoid valve is used inReverse Osmosis System.The valve is assembled with high quality copper wire solenoid coil, and no leaking armature tube assembly. The valve body is made of Plastic (PP,POM,Nylon). All water Purifier products available in RO are made of food grade plastic for retaining the purity of the soft water .



Reverse Osmosis systems

A simple reverse osmosis system consists of a high-pressure pump which increases the pressure of the feed water with salts, ions or impurities. This forces the water across the semi permeable RO (Reverse Osmosis) membrane, leaving behind all the dissolved salts. The required pressure is directly proportional to the salt concentration of the inlet water. The higher the concentration, the higher pressure is required to overcome the osmotic pressure.

The RO membrane lets the cleaner water through and this is called permeate water. The salts and other contaminants which are stopped by the membrane come out as a reject stream. This can be drained out or recycled if possible through the RO system to save water.

The RO systems remove up to 99% of dissolved salts (ions), particles, pathogens and bacteria from feed water.


No concentrated water is discharged from the concentrated water pipe
No concentrated water is discharged from the concentrated water pipe, and the TDS value of pure water is the same as that of tap water
Possible reasons:
◆ It may appear after the product has just been installed, the water machine has been disassembled in a larger area, or after the new installation. It may be wrong to connect the water pipe between the high-pressure pump and the RO membrane membrane shell directly to the tee of the rear activated carbon, so that the tap water from the high-pressure pump directly enters the water storage bucket.
Approach:
◆ Correct connection


Place of Origin: Zhejiang, China
Brand Name: Brando
Model Number:
BPV10
Application:ro system,water dispenser, RO system
Material:PP,POM,Nylon
Temperature of Media:Medium Temperature
Pressure:Medium Pressure, max 8 bar
Power:Solenoid
Media:water,air
Port: NPT1/4''

Structure:direct acting, direct acting
Standard or Nonstandard:Standard
Temperature:Medium


Main Dimension of RO Solenoid Water Valve:
Main Dimension of RO Solenoid Water Valve:

Technical data:

Characteristic1)Direct acting,0 rated bar pressure.low power
2)compact design to save the space
MediumAir,water,steam,oil,etc.
Temperature

NBR: -10°C to 80 °C

EPDM: -10°C to 120 °C

FKM:-10°C to 150 °C

Pressure0-1.6Mpa
Port Size1/2''
Port ThreadG, NPT
Orifice2.5mm
Voltage

DC-12V,24V

AC-24V,120V,110V,220V/50HZ

Voltage Range±10%
Material

Body-Nylon,PP,POM
Seal-NBR, EPDM,FKM

Amature tube-stainless steel 304

Plunger-stainless steel430F

Stop-stainless steel 430F

Springs-SS304

Shading rings- stainless steel 304


Brando Factory Production of Solenoid Valves:


18 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve 1


Feature:
The solenoid valve is usually used for RO purifier water treatment, with DC24V DC36V voltage option. The valve is assembled with high quality copper wire solenoid coil, and no leaking armature tube assembly. The valve body is made of POM, delrin material, with good performance of strength. And also we assemble special designed o-ring to ensure no leaking while valve working.
Turn on water when system start;and cut off water when system stop.
Domestic RO based water system uses water solenoid valve to control feed and in membrane flushing. Due to lower inlet pressure, pilot operated valves cannot give adequate flow. All water Purifier products available in RO are made of food grade plastic for retaining the purity of the soft water .

1.Solenoid valves are the most frequently used control elements in fluidics.
2.Their tasks are to shut off, release, dose, distribute or mix fluids.
3.They are found in many application areas.
4.Solenoids offer fast and safe switching, high reliability, long service life, good medium compatibility of the materials used, low control power and compact design.


18 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve 218 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve 318 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve 418 Seconds Delay Auto Flush For Domestic Ro System Plastic Water Latching Solenoid Valve 5
Reverse Osmosis systems
A simple reverse osmosis system consists of a high-pressure pump which increases the pressure of the feed water with salts, ions or impurities. This forces the water across the semi permeable RO (Reverse Osmosis) membrane, leaving behind all the dissolved salts. The required pressure is directly proportional to the salt concentration of the inlet water. The higher the concentration, the higher pressure is required to overcome the osmotic pressure.
The RO membrane lets the cleaner water through and this is called permeate water. The salts and other contaminants which are stopped by the membrane come out as a reject stream. This can be drained out or recycled if possible through the RO system to save water.
The RO systems remove up to 99% of dissolved salts (ions), particles, pathogens and bacteria from feed water.
