1/2" 3/4" PA66 Nylon Plastic Electric Solenoid Valve Normally Open 12V 24V DC 220V AC

1/2'' 3/4'' PA66 Nylon Plastic Electric Solenoid Valve Normally Open 12V 24V DC 220V AC

Product Features:

1. Port Size: 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2''; Thread Port (G, NPT).

2. Orifice Size: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm.

3. Function: 2 Way, Normally Open.

4. Body Material: PA66 (Nylon)

5. Seal Material: NBR

6. Working Medium: Water, Liquid, Gas, Air

7. Fluid Temperatrue: -5 to +80℃

8. Voltages: 110VAC, 220VAC, 12VDC, 24VDC, other voltages can be customized.

2 way normally closed electric plastic solenoid valve is to control On/Off of air, inert gas, liquid, and vacuum. This plastic solenoid valve has one 3/4" inch NPT inlet and one 3/4" inch NPT outlet port. This plastic solenoid valve comes with a ED 100% encapsulated coil which suitable to operate in continuous service and constantly energized. Valve can be mounted in any position.

Dimension & Data of PA66 Nylon Plastic Solenoid Valve:

Brando Factory Production of Solenoid Valves:

More Plastic Solenoid Valves for you to choose:

1. According to Body Material: Brass Solenoid Valve, Stainless Steel Solenoid Valve, Plastic Solenoid Valve

2. According to Valve Operation: Direct Acting Solenoid Valve, Semi Direct Acting Solenoid Valve, Pilot Operated Diaphragm Valve, Pilot Operated Piston Valve.
