| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | BB12039508 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Ref Number: | K0303 | Hole Size: | 12mm |
|---|---|---|---|
| Height: | 41mm | Width: | 37.5mm |
| Voltage: | 110V DC | Power: | 20Watt |
| Connector: | DIN43650A | Insulation Class: | F, H |
| Protection Class: | IP64 | Application: | Goyen Type Dust Collector Pulse Valve |
| High Light: | Pulse Valve Solenoid Coil,Solenoid Coil For Pulse Valve,Pulse Valve Coil |
||
Goyen Type Pneumatic Solenoid Coil K0303 CY123 QR N282 C53056N 110V DC
The main pulse valve industry reduced environmental dust, etc. is controlled by electromagnetic or pneumatic pilot valve can open and close the high-pressure source of gas instantaneously generated pulse valve diaphragm valves, but also known as electromagnetic pulse valve or pneumatic pulse valve, respectively.
The electromagnetic pulse valve (also called diaphragm valve) is the compressed air "switch" of the dust blowing system of the pulse bag dust collector. Under the control of the output signal of the pulse controller, the filter bags are sprayed row by row (chamber) to clean the dust, so that the resistance of the dust collector is kept within the set range to ensure the processing capacity and dust collection efficiency of the dust collector.
Hole Size: 12mm
Height: 41mm
Width: 37.5mm
Voltage: 110V DC
Power: 20Watt
Connector: DIN43650A
Insulation Class: F.H
Protection Class: IP64
Application: Goyen Type Dust Collector Pulse Valve
Dimension:
Technical Data:
| Model No. | BB12039508 |
| Normal voltage | 110VDC |
| Normal power | AC:25VA DC20W |
| Insulation class | H, F |
| Connection type | DIN43650A |
| Application | Goyen type pulse solenoid valve |
| Weight | 142.5 g |
|
Code
|
Type
|
Class
|
Voltage
|
Inrush
(mA)
|
Hold
(mA)
|
Power
|
|
K0300
|
QR
|
IP64
|
200/240V 220V AC 50/60Hz
|
1338/1096
|
963/716
|
23.1VA
|
|
K0301
|
QR
|
IP64
|
100/120V 110V AC 50/60Hz
|
234/225
|
180/152
|
19.8VA
|
|
K0302
|
QR
|
IP64
|
24V AC 50/60Hz
|
1338/1096
|
963/716
|
23.1VA
|
|
K0303
|
QR
|
IP64
|
110V DC
|
212
|
212
|
24W
|
|
K0304
|
QR
|
IP64
|
48V DC
|
429
|
429
|
20W
|
|
K0305
|
QR
|
IP64
|
24V DC
|
873
|
873
|
20W
|
|
K0306
|
QR
|
IP64
|
12V DC
|
1644
|
1644
|
20W
|
Application Example:
Product Characteristic:
1. Using high quality wire which has UL approved;
2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
