K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil

K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil

  • K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil
  • K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil
  • K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil
K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BB12039508
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Hole Size: 12mm Height: 41mm
Width: 37.5mm Voltage: 100/120V 110V AC
Power: 20Watt Connector: DIN43650A
Insulation Class: F, H Protection Class: IP64
Application: Goyen Type Dust Collector Pulse Valve
High Light:

Pulse Valve Solenoid Coil

,

Solenoid Coil For Pulse Valve

,

Pulse Valve Coil

K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil



Pulse valve refers to a diaphragm valve controlled by a pilot valve such as electromagnetic or pneumatic, which can open and close a high-pressure gas source to generate a pulse in an instant. The pulse valve is the main component of the bag dust collector, and it has been sprayed more than 1 million times. Pulse valve is a kind of valve that makes the long signal input into a pulse signal by the delay action of air flow through air resistance and gas volume.

We also have K0300 (AC220V), K0301 (AC110V), K0302 (AC24V), K0303 (DC110V), K0304 (DC48V), K0305 (DC24V), K306 (DC12V).

Hole Size:12mm
Height:41mm
Width:37.5mm
Voltage:100/120V 110V AC
Power:20Watt
Connector:DIN43650A
Insulation class:F, H
Protection class:IP64
Application:CA Dust Collector Pulse Valve



Dimension:

K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil 0



Technical Data:

Model No. BB12039508
Normal voltage AC110V
Normal power AC:25VA DC20W
Insulation class H, F
Connection type DIN43650A
Application Goyen type pulse solenoid valve
Weight 142.5 g



Code
Type
Class
Voltage
Inrush
(mA)
Hold
(mA)
Power
K0300
QR
IP64
200/240V 220V AC 50/60Hz
1338/1096
963/716
23.1VA
K0301
QR
IP64
100/120V 110V AC 50/60Hz
234/225
180/152
19.8VA
K0302
QR
IP64
24V AC 50/60Hz
1338/1096
963/716
23.1VA
K0303
QR
IP64
110V DC
212
212
24W
K0304
QR
IP64
48V DC
429
429
20W
K0305
QR
IP64
24V DC
873
873
20W
K0306
QR
IP64
12V DC
1644
1644
20W



Application Example:

K0301 100/120V 110V AC 50/60Hz CY123 QR N282 C53056N Goyen Type Pulse Valve Replacement Solenoid Coil 1


Product Characteristic:
1. Using high quality wire which has UL approved;
2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
