Goyen Type1" K2501 M1183B K2502 M736 K2503 M1887 Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust Collector Valve

Goyen Type1" K2501 M1183B K2502 M736 K2503 M1887 Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust Collector Valve

  • Goyen Type1" K2501 M1183B K2502 M736 K2503 M1887 Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust Collector Valve
  • Goyen Type1" K2501 M1183B K2502 M736 K2503 M1887 Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust Collector Valve
  • Goyen Type1" K2501 M1183B K2502 M736 K2503 M1887 Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust Collector Valve
Goyen Type1" K2501 M1183B K2502 M736 K2503 M1887 Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust Collector Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: G25
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Name: K2501(M1183B) K2502(M736) K2503(M1887) Goyen Type Pulse Valve Diaphragm Repai Kits Size: For 1'' Pulse Valve
Material: Nitrile / Buna/FKM Suitable Valve Number: CA/RCA/RCAC 25
Mounting Hole Size:: 9mm Diaphragm Outer Distance:: 80mm
Sealing Gasket OD: 47mm Sealing Gasket ID: 27.5mm
Air Hole: With
High Light:

Goyen Membrane

,

Goyen Diaphragm Kit

,

Goyen Diaphragm Valve Repair Kit

Goyen Type1'' K2501(M1183B) K2502(M736) K2503(M1887) Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust collector Valve


Name: K2501(M1183B) K2502(M736) K2503(M1887) Goyen Type Pulse Valve Diaphragm Repai Kits
Size: For 1'' Pulse Valve
Material: Nitrile / Buna/FKM
Suitable Valve Number: CA/RCA/RCAC 25
Mounting Hole Size: 9mm
Diaphragm Outer Distance: 80mm
Sealing Gasket OD: 47mm
Sealing Gasket ID: 27.5mm
Air Hole: With



Dimension:

Dimenion of Goyen Type1'' K2501(M1183B) K2502(M736) K2503(M1887) Solenoid Valve Diaphragm For CA/RCA/RCAC 25 Dust collector Valve

Reference Number:

Material
Repair Kit
Fitted Valve Model
Port Size
Buna/Nylon
K2000(M1204B)
CA20, RCA20, RCAC20
3/4''
K2003(M1174B)
K2016
K2034
Buna/Buna
K2002(M764)
FKM
K2007(M2080B)
K2004(1328B)
K2017
K2033
Buna/Nylon
K2501(M1183B)
CA25, RCA25, RCAC25
1''
K2529
K2549
K2531
K2545
K2546
Buna/Buna
K2502(M736)
FKM
K2503(M1887)
K2530
K2532
K2551
Buna/Nylon
K2500(M1183)
CA32, RCA32, CA35, RCA35,
CA40, RCA40, CA45, RCA45
1-1/2''
K3500(M1581)
K4000(M1182)
K4502(M2162)
Buna/Buna
K3502(M1591)
K4504(M2187)
FKM
K2503(M1887)
K4004(M1761)
K4007(M1156)
K4503(M2163)
Buna/Nylon, Buna/Buna
K5004(M1638A)
CA50, RCA50, CA62, RCA62
2'' , 2-1/2''
K5005(M1639A)
FKM
K5000(M1157A)
K5002(M1528A)
Buna/Nylon, Buna/Buna
K7600
CA76, RCA76
3''
K7604
K7610
FKM
K7602
Buna/Nylon
K10200
CA102, RCA102
4''
Buna/Buna
K10203
FKM
K10201
Buna/Nylon, Buna/Buna
K8000
CA8, RCA8
8''
FKM




Troubleshooting and Repair of the Diaphragm

1, spring damage, pulse valve spring on the spool is easy to damage, the appearance of the pulse valve is a long-term blow to the nozzle, the treatment is to replace the spring.

2, rubber mat damage, after a long time of use, the rubber pad on the pulse valve spool is easy to damage, the appearance is that the pulse valve for a long time to blow air into the nozzle, the treatment is to replace the rubber pad.

3, valve core dirt, because the air intake is not clean, cause the dirt accumulation at the valve core, the appearance is the nozzle long air intake or power pulse valve does not work, the treatment is to clean the valve core.

4. The diaphragm is damaged. After long-term operation, the diaphragm is prone to fatigue and oxidation.

5. The throttle hole is blocked or damaged, and the inlet air is not clean, which will easily lead to the throttle hole blocking. The appearance is that the pulse valve has been blowing air to the nozzle for a long time, and the treatment is to clean the throttle hole. The damage or loss of the throttle orifice makes the throttle orifice lose its interception function, resulting in abnormal pressure relief. the pulse valve after receiving electricity, and the pressure relief orifice releases air, but the pulse valve does not spray, and the treatment mode is to replace the throttle orifice.



Features:

1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.

2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.

3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.

4. Facbric-reinforced diaphragms advantages:
*No leakage *No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility

5. EPDM, FKM all available.



Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change

√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
