Name: C113827 1-1/2" ASCO Type Solenoid Valve Diaphragm For SCG353A047 Dust Collector Valve Spare Parts
Brand: Brando
SKU: A047
Rating: 4.6 (130 reviews)

Home Products Diaphragm Repair Kit

C113827 1-1/2" ASCO Type Solenoid Valve Diaphragm For SCG353A047 Dust Collector Valve Spare Parts

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	A047

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Name:	C113827 ASCO Type Pulse Valve Diaphragm Repair Kits	Size:	For 1-1/2'' Pulse Valve
Material:	NBR Nitrile	Suitable Valve Number:	SCG353A047
Mounting Hole Size:	8.5mm	Diaphragm Outer Distance:	112mm
Center Distance:	116.5mm	Sealing Gasket:	Without
High Light:	ASCO Diaphragm , ASCO Pulse Valve Diaphragm , ASCO Membrane

C113827 1-1/2'' ASCO Type Solenoid Valve Diaphragm For SCG353A047 Dust Collector Valve Spare Parts

This is C113827 1-1/2'' solenoid valve diaphragm repair kits for SCG353A047 electromagentic pulse jet valve. C113825 / C113826 / C113827 diaphragm repair kit for ASCO 1 1/2'' G353A045, G353A046, SCG353A047, SCG353A065 diaphragm valves.

Name:C113827 ASCO Type Pulse Valve Diaphragm Repair Kits Size:For 1-1/2'' Pulse Valve
Material:NBR Nitrile
Suitable Valve Number:SCG353A047
Mounting Hole Size:8.5mm
Diaphragm Outer Distance:112mm
Center Distance:116.5mm
Sealing Gasket:Without

Dimension:

C113827 1-1/2" ASCO Type Solenoid Valve Diaphragm For SCG353A047 Dust Collector Valve Spare Parts 0

Reference Number:

Ordering Code	Fitted Valve Code	Valve Port Size	Material
C113443	G353A041, G353A042	3/4'', 1''	TPU/NBR
C113444	SCG353A043, SCG353A044, SCG353-052, SCG353-053	3/4'', 1''	TPU/NBR
C113825	G353A045	1-1/2''	NBR
C113826	G353A046	1-1/2''
C113827	SCG353A047, SCG353A065	1-1/2''
C113685	SCG353A050, SCG353A051	2'', 2-1/2''
C113686	SCG353A050, SCG353A051	2'', 2-1/2''
C113928	SCEX353.060	3''
C123432	SCG353D060, G353.060
C123433	SCG353D060, G353.060
K096875 (K238864)	8353C033	3/4''
K200262 (K238866)	G353A041, G353A042, SCG353A043, SCG353A044, SCG353-052, SCG353-053	1''
K276886 (K238870)	G353A045, G353A046, SCG353A047, SCG353A065	1-1/2''
K276886B
K276887			Viton
Tips: EPDM, FKM All Available.

Features:

1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.

2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.

3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.

4. Facbric-reinforced diaphragms advantages:
*No leakage *No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility

5. EPDM, FKM all available.

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change

√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
