TPE Vition 1268274 2" 8296700 2 1/2" 8296800 Solenoid Valve Repair Kit Diaphragm Solenoid Valve Diaphragm Norgren Type

TPE Vition 1268274 2" 8296700 2 1/2" 8296800 Solenoid Valve Repair Kit Diaphragm Solenoid Valve Diaphragm norgren Type

The diaphragm of the solenoid valve is a circular membrane like elastic sensing element. When two sides of the diaphragm are affected by different pressures (or forces), the diaphragm moves towards the side with low pressure and strain, so that the center of the diaphragm has a certain displacement related to the pressure difference. There are mainly three types of diaphragm: flat diaphragm, vertical chain diaphragm and corrugated diaphragm. The flat diaphragm can also be fixed and supported according to the surrounding, Whether the center is open or not and the stress distribution of the diaphragm area are different can be divided into various forms, among which the flat diaphragm is usually composed of circular plates with constant cross-section fixed around. The vertical chain diaphragm is composed of circular plates with grooves near the edges, and its elastic strain mainly occurs in the circular grooves at the edges, This kind of diaphragm is often used to compress the strain tube or column to achieve the purpose of pressure measurement. The professional production base of solenoid valve diaphragm, the leading enterprise of solenoid valve diaphragm in Hebei Province, Huajie solenoid valve diaphragm is one of the accessories for the normal operation of the valve body and the "switch" of the air injection circuit of the dust cleaning system of the pulse bag filter On the basis of the previous experience in the production of solenoid valve diaphragm, absorbing and summarizing the advantages of materials and production technology of similar products at home and abroad, the improved solenoid valve diaphragm and pulse valve diaphragm are newly developed. The electromagnetic pulse valve diaphragm is suitable for the production of rubber plate for the production of solenoid valve diaphragm, which has strong oil resistance, acid resistance, high temperature resistance, alkali resistance and other characteristics, and can easily guarantee the quality of other control components Fully synchronous operation, control pulse compressed air injection. Even in the extremely bad working environment, it can guarantee its normal operation and long service life. At the ambient temperature of - 20-80 ℃ and the working pressure difference of 0.8MPa, the working life of the diaphragm is not less than 1 million times.

Main dimension of Norgren Type Pulse Valve Diaphragm Kit:

Details of Repair Kit Diaphragm For Norgren solenoid Valve:

Available Models of Diaphragm Valve Repair Kits For Norgren Pulse Valves:

YouTube video of Norgren Diaphragm Repair Kit For Norgren Pulse Valve:

Factory Production Pictures of Solenoid Valve Diaphragm Kits:

Diaphragm Features:

1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.

2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.

3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.

4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility

5. EPDM, Viton all available.

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
