Detailed Product Description
Product Name: Diaphragm Repair Kit Suitable Valves: AE1440B, AE1440R, AE2440B, AE2440R
Suitable Valve Port Size: 1 1/2'' Diaphragm Material: TPE
Diaphragm Outer Diameter: φ106.0mm Seat OD: φ61.0mm
Seat ID: φ35.0mm Bleed Hole: 1
Spring: Without Packaging: Individual Plastic Bag Sealed
High Light:

Norgren Diaphragm

,

Norgren Pulse Valve Diaphragm

,

Norgren Membrane

TPE Vition 1261402 1 1/2" 8296600 Diaphragm Pneumatic Valve Repair Kit Solenoid Valve Repair Kits



As the diaphragm of pulse solenoid valve is a flexible mechanism which needs to be opened and closed frequently to control the air flow, and requires good flexibility, as well as high sealing as possible, so the material of the diaphragm of pulse valve is directly related to the service life and effect of the diaphragm of pulse valve.



Working principle of solenoid valve diaphragm: make the diaphragm in the key position. The electric signal is input by the pulse controller, which makes the electromagnetic pilot head attractive and transportable, and opens the unloading hole. The pressure gas controlled by the diaphragm is discharged rapidly. The pressure gas controlled in front of the diaphragm lifts the diaphragm, opens the channel of the solenoid valve and sprays into the street, the electrical signal disappears, the spring of the electromagnetic pilot head makes the Dongzhu immediately reset and close the unloading hole, the pressure of the gas and the force of the spring controlled in the back of the diaphragm make the diaphragm close the channel, the electromagnetic pulse valve sprays, the resistance hole on the diaphragm, when the dynamic column of the pilot head is lifted and the gas pressure is unloaded, the resistance air flow is started When the unloading is closed, the pressure gas will be filled into the rear chamber quickly, the fragment will close the passage and stop blowing.



Main dimension of Norgren Type Pulse Valve Diaphragm Kit:

TPE Vition 1261402 1 1/2" 8296600 Diaphragm Pneumatic Valve Repair Kit Solenoid Valve Repair Kits 0



Details of Repair Kit Diaphragm For Norgren solenoid Valve:

TPE Vition 1261402 1 1/2" 8296600 Diaphragm Pneumatic Valve Repair Kit Solenoid Valve Repair Kits 1



Available Models of Diaphragm Valve Repair Kits For Norgren Pulse Valves:

Ordering Code
Fitted Valve Code
Valve Port Size
Material
1261253
8296300
3/4''
TPE
1261253
8296400
1''
TPE
1261402
8296600
1.5''
TPE
1268274
8296700
2''
TPE
1268274
8296800
2.5''
TPE
1271526
8296900
3''
TPE



YouTube video of Norgren Diaphragm Repair Kit For Norgren Pulse Valve:



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

TPE Vition 1261402 1 1/2" 8296600 Diaphragm Pneumatic Valve Repair Kit Solenoid Valve Repair Kits 2



Diaphragm Features:


1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.



2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.



3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.



4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility



5. EPDM, Viton all available.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
