Home ProductsDiaphragm Repair Kit

K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve

K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve

  • K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve
  • K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve
K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: K2034
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Goyen Type K2034 Shockwave Diaphragm Kit Diaphragm Material: TPE
Mounting Hole Size: 8.5mm Diaphragm OD: 72mm
Center Distance: 76mm Seat OD: 34mm
Seat ID: 16mm Air Hole: With
Packaging: Individual Sealed Suitable Valves: K2034 Shockwave Diaphragm For Goyen RRCAC20T4, RCAC20ST4, RCAC20DD4, RCAC20FS4
High Light:

Goyen Diaphragm

,

Goyen Pulse Valve Diaphragm

,

Goyen Diaphragm Repair Kit

K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve



The shown is K2034 shockwave diaphragm repair kit for repair and replace Goyen RCAC20T4, RCAC20ST4, RCAC20DD4, RCAC20FS4 remote pilot pulse valve diaphragm. Because the diaphragm of pulse valve is a flexible mechanism which needs to open and close frequently to control the air flow, it requires good flexibility and as high sealing as possible. This diaphragm is made of TPE, which has many advantages, like Good chemical resistance, Aging resistance, Can be used in a wide temperature range from -40 ℃ to 85 ℃, Service life is 4-5 times longer than that of comparable, conven-tional fabric diaphragms.



1. Product Name: K2034 Shockwave Kit RCAC20T4,ST4,DD4,FS4
2. Diaphragm Material: TPE
3. Diaphragm Outer Distance: 72mm
4. Center Distance: 76mm
5. Mounting Hole Size: 8.5mm
6. Seat OD: 34mm
7. Seat ID: 16mm
8. Spring: Without
9. Air Hole: With
10. Packaging: Individual Sealed


YouTube video of K2034 Shockwave Kit RCAC20T4, ST4, DD4, FS4:


Main dimension of K2034 Goyen Type Shockwave Diaphragm Repair Kit:
K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve 0
Details display of K2034 Goyen Type RCAC20 Diaphragm Valve Repair Kit:
K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve 1

Available Models of Goyen Type 3/4'' RCA/RCAC Diaphragm Valve Repair Kits:

Models Material Available Valve
K2000 Buna (R)CA20T, DD
K2007 Viton/Viton (R)CA20T, DD
K2003 Buna/Nylon (R)CA20M
K2004 Viton/Viton (R)CA20M
K2017 Buna/Nylon (R)CAC20 (Millennium)
K2016 Viton/Viton (R)CAC20 (Millennium)
K2034 Shockwave (R)CAC20T4, ST4, DD4, FS4
K2033 Viton/PTFE (R)CAC20T4, ST4, DD4, FS4


Factory Production Pictures of Solenoid Valve Diaphragm Kits:

K2034 Shockwave Diaphragm For Goyen RCAC20T4 RCAC20ST4 RCAC20DD4 RCAC20FS4 Pulse Valve 2



Brief introduction of K2034 Shockwave Kit:



1. K2034 pulse valve repair kit mounted on RCAC20T4, RCAC20ST4, RCAC20DD4 & RCAC20FS4 diaphragm valves is a shockwave springless diaphragm. The pulse valves with shockwave diaphragm are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.



2. Proprietary highperformance engineering thermoplastic Elastomer (TPE).



3. The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life.



4. Working Principle: When different pressure (or force) acts on both sides of the diaphragm of the pulse valve, the diaphragm moves to the lower side of the pressure, resulting in the displacement of the center of the diaphragm.
