ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector

ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector

    • ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector
    • ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector
    • ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector
    • ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector
  • ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: G353A045

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Inner Box, Carton, Pallet
    Delivery Time: 4-7 days
    Payment Terms: L/C, T/T, Western Union, Paypal
    Supply Ability: 100000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: G353A045 Remote Pilot Pulse Valve Port Size: 1 1/2''
    Remote Or Integral: Remote Pilot Remote Pilot Connection: 1/4''
    Body Material: Aluminum Diecast Diaphragm Material: NBR (Buna)
    Pressure: 0.35 To 0.85 MPa Temperature Of Media: -10 To +70℃
    Valve Type: 2/2 Way Function: Normally Closed (NC)

    ASCO Type G353A045 1 1/2'' Pipe 1/4'' Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector



    Brando has more than 10 years experiences in manufacturing and exporting diaphragm valves and their diaphragm repair kits. The valve shown is 1 1/2'' G353A045 ASCO replacement remote pilot diaphragm valve for pulse jet dust collector.



    1. Product Name: G353A045 Remote Pilot Pulse Valve
    2. Actuation: Air
    3. Port Size: 1 1/2''
    4. Remote or Integral Pilot: Remote Pilot
    5. Remote Pilot Connection: 1/4''
    6. Valve Type: 2 Way
    7. Function: Normally Closed
    8. Diaphragm Material: NBR (Buna)
    9. Body Material: Aluminum ADC12
    10. Working Pressure: 0.35 to 0.85 MPa
    11. Working Temperature: -10 to +70℃



    YouTube video of G353A045 ASCO Type Remote Pilot Pulse Valve:


    Main dimension of G353A045 1.5'' Dust Collector Diaphragm Valve:

    ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector

    Model No

     A (mm)

    B
    C
    (mm)
    D
    (mm)
    E
    (mm)
    F
    (mm)
    G
    (mm)
    Weight
    (kg)
    G353A041
    -
    1/8''
    51
    89
    75
    41
    64
    0.45
    G353A042
    -
    1/8''
    51
    89
    75
    41
    64
    0.40
    G353A045
    30
    1/4''
    71
    130
    136
    71
    98
    1.00



    Details of G353A045 ASCO Replacement Dust Collector Pulse Valve:

    ASCO Type G353A045 1 1/2" Pipe 1/4" Remote Pilot Diaphragm Valve For Pulse Jet Dust Collector



    Technical parameters of G353 Series ASCO Type Remote Pilot Pulse Valves:

    Port
    Size
    Remote Pilot Connection
    Office Size
    Operating Pressure Differential (Bar)
    Model Number
    Diaphragm Material
    G
    φB
    (mm)
    Min.
    Max.
    Aluminium



    NBR/Viton
    3/4''
    1/8''
    24

     0.35

    8.5
    G353A041
    1''
    1/8''
    27
    0.35
    8.5
    G353A042
    1 1/2''
    1/8''
    52
    0.35
    8.5
    G353A045



    Installation:
    1. The valves can be mounted in any position without affecting operation;


    2. Threaded pipe connection is: G = G (ISO 228/1) or compression fittings;


    3. When connecting piping or tubing to the G1/8 connection in the valve bonnet, the remote ASCO pilot valve should be mounted as close as possible to the main pulse valve. Connection tubing lengths of 3 meter or less have little effect on the pulse response. Installations with over 3 meter of tubing must be tested under actual operating conditions. Tubing with Φ 6 mm O.D. is recommended for all installations;


    4. For compression fitting types tightness is achieved by the compressed gasket on the blow tube;


    5. Other pipe threads are available on request;


    6. Installation/maintenance instructions are included with each valve;


    7. Spare parts kit and replacement coils are available.
