This TPE dipahragm repair kit is use in AUTEL 3/4'' AE1818B and AE2818B pulse valves. Because the diaphragm of pulse valve is a flexible mechanism which needs to open and close frequently to control the air flow, it requires good flexibility and as high sealing as possible. This diaphragm is made of TPE, which has many advantages as following:
1. Good chemical resistance
2. Aging resistance
3. Can be used in a wide temperature range from -40 ℃ to 85 ℃
4. Service life is 4-5 times longer than that of comparable, conven-tional fabric diaphragms.
YouTube video of TPE Diaphragm Repair Kit For AUTEL Pulse Valve:
Main dimension of Diaphragm Repair Kit For 3/4'' AUTEL Pulse Valve:
Details of Diaphragm For AUTEL 3/4'' AE1818B AE2818B Pulse Valve:
Available Models of Diaphragm Valve Repair Kits For AUTEL Pulse Valves:
Ordering Code
Fitted Valve Code
Valve Port Size
Material
AE20
AE1818B, AE2818B
3/4''
TPE
AE25
AE1825B, AE2825R
1''
TPE
AE40
AE1440B, AE1440R
AE2440B, AE2440R
1-1/2''
TPE
AE50-60
AE1450B, AE2450R,
AE1460B, AE2460R
2'', 2-1/2''
TPE
AE75
AE1475I12
3''
TPE
Tips: FKM+PTFE also available
Factory Production Pictures of Solenoid Valve Diaphragm Kits:
Diaphragm Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility
5. EPDM, Viton all available.
