4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V

4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V

    • 4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V
    • 4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V
    • 4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V
    • 4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V
  • 4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: 4V320-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    In& Out Port Size: 3/8'' Exhaust Port Size: 1/4''
    Action: Internally Pilot Valve Type: 5/2 Way Double Solenoid Valve
    Max.Frequency: 4 Cycle/sec Application: Automation (LIKE Automatic Medical Mask Machine)
    Voltage: AC220V AC110V DC24V DC12V

    4V320-10 5/2 Way 3/8'' Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V

    4V320-10 pneumatic air control solenoid valve inlet=outlet=3/8'', exhaust port =1/4''.Widely used in automation machine In various industries, such as Medical, food, chemical.

    When the electrical part is charged, the electromagnetic coil generates electromagnetic force to lift the closing member from the sealed air hole, compressed air enters the pilot valve, and the pilot valve works; when the power is turned off, the electromagnetic force disappears and the valve action is reversed.



    Youtube Video of 3/8''AirTAC Type Solenoid Valve:



    Dimension:

    dimension

    Ordering code:

    Model 4V 2(3) Position 5 Way
    Code 3 300 Series
    Valve Type 20

    10:Single solenoid 5/2 way

    20:Double solenoid 5/2 way

    30C:Double solenoid 5/3 way closed center

    30E:Double solenoid 5/3 way exhaust center

    30P:Double solenoid 5/3 way pressure center

    Port Size 10

    M5:M5x0.8

    06:1/8''

    08:1/4''

    Voltage -

    A: AC220V

    B: DC24V

    C: AC110V

    E: AC24V

    F: DC12V

    Electrical Entry -

    Blank:Terminal

    I:Grommet

    Thread Type -

    Blank:PT

    G:G

    T:NPT

    Specifications:


    Model
    4V310-08
    4V320-08
    4V330C-08
    4V330E-08
    4V330P-08
    4V310-10
    4V320-10
    4V330C-10
    4V330E-10
    4V330P-10
    Fluid
    Air(to be filtered by 40 μ m filter element)
    Acting
    Internal pilot or external pilot
    Port Size
    In=Out=Exhaust=1/4''
    In=Out=3/8'' Exhaust=1/4''
    Orifice Size
    25.00 mm2 (Cv=1.40)
    18.00 mm2 (Cv=1.00)
    30.00 mm2 (Cv=1.68)
    18.00 mm2 (Cv=1.00)
    Valve Type
    5 port 2 position
    5 port 3 position
    5 port 2 position
    5 port 3 position
    Operating Pressure
    0.15~0.8MPa(21~114psi)
    Proof Pressure
    1.5MPa(215psi)
    Temperature ℃
    -20~70
    Material of Body
    Aluminum alloy
    Max. frequency
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec




    Details:

    4V320-10 5/2 Way 3/8" Double Coil Electrical Solenoid Valve Internally Piloted AC220V DC24V DC12V



    Product Features:
    1. Pilot-oriented mode: Internal pilot or external pilot.
    2. Structure in sliding column mode: good tightness and sensitive reaction.
    3. Three position solenoid valves have three kinds of central functionfor your choice.
    4. Double control solenoid valves have memory function.
    5. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life.
    6. No need to add oil for lubrication.
    7. It is available to form integrated valve group with the base to save installation space.
    8. Affiliated manual devices are equipped to facilitate installation and debugging.
    9. Several standard voltage grades are optional.
