Nitrile NBR Buna 3 Inch Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80

Nitrile NBR Buna 3 Inch Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80

  • Nitrile NBR Buna 3 Inch Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80
  • Nitrile NBR Buna 3 Inch Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80
Nitrile NBR Buna 3 Inch Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: J89
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Name: Diaphragm Repair Kit Suitable Valves: JISI 80, JISR 80, JIHI 80, JIHR 80
Diaphragm Material: NBR (Nitrile) Mounting Hole Size: φ10mm
Diaphragm Outer Diameter: φ193mm Center Distance: φ193mm
Seat Material: NBR (Nitrile) Seat OD: φ102mm
Seat ID: φ51mm Bleed Hole: 1
Packaging: Individual Plastic Bag Sealed
High Light:

Joil Diaphragm

,

Joil Pulse Valve Diaphragm

,

Joil Pulse Valve Repair Kit

Nitrile NBR Buna 3'' Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80



This is Buna (NBR) Diaphragm Kit includes one NBR seat NBR diaphragm and one secondary diaphragm, which is used in joil 3 inch JISI 80, JISR 80, JIHI 80, JIHR 80 pulse jet valves. The diaphragm consists of one or more layers coated on both sides. Diaphragms of different materials can be manufactured according to the requirements of use. The working temperature and pressure range of the diaphragm itself depends on the type of rubber, fabric and structure. The diaphragm can work at -10~80℃, 0.4~0.8 MPa, and the fluororubber and silicone rubber diaphragm can work at -80~232℃.



YouTube video of Diaphragm Repair Kit For 3'' Joil Pulse Valve:



Main dimension of JISI 80 JISR 80 JIHI 80 JIHR 80 NBR Diaphragm:

Nitrile NBR Buna 3 Inch Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80 0



Details display of JISI 80 JISR 80 JIHI 80 JIHR 80 Valve Diaphragm:

Nitrile NBR Buna 3 Inch Pulse Valve Diaphragm For Joil JISI 80 JISR 80 JIHI 80 JIHR 80 1



Available Models of Diaphragm Valve Repair Kits For Joil Pulse Valves:

Ordering Code
Type
Quatity
Suitable valve
Material
J20
3/4''
1
JICI 20, JICR 20,
JISI 20, JISR 20
Nitrile/Buna
J25
1''
1
JICI 25, JICR 25,
JISI 25, JISR 25
J40 & JTY-X
1 1/2''
2
JICI 40, JICR 40,
JISI 40, JISR 40,
JIFI 40, JIFR 40
J50 & JTY-X
2''
2
JISI 50, JISR 50,
JIFI 50, JIFR 50
J76 & JTY-X
2 1/2''
2
JISI 65, JISR 65,
JIFI 65, JIFR 65
J89 & JTY-X
3''
2
JISI 80, JISR 80,
JIHI 80, JIHR 80
J102 & JTY-X
4''
2
JIHI 100, JIHR 100



Tips: The related solenoid coils and armature assembly are all supplied.



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12



Diaphragm Features:


1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.



2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.



3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.



4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility



5. EPDM, Viton all available.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
