Place of Origin: | China |
Brand Name: | Brando |
Certification: | CE |
Model Number: | 4V210-08 |
Minimum Order Quantity: | 1 pc |
---|---|
Packaging Details: | inner boxes,cartons,pallets |
Delivery Time: | 7 working days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100000pcs per month |
In & Out PortSize: | 1/4'' | Exhaust Size: | 1/8'' |
---|---|---|---|
Valve Type: | 5/2 Way Solenoid Valve | Action Type: | Internally Pilot Operated |
Cinnection Type: | Threaded | Pressure: | 1.5~8kgf/cm2 |
Max. Frenquency: | 5 Cycle/sec | Application: | Automation (Automatic Medical Mask Machine) |
Voltage: | AC220V AC110V DC24V DV12V | ||
High Light: | electric solenoid valve,solenoid pneumatic valve |
AirTAC Type 5/2 Way 1/4'' 4V210-08 Pneumatic Air Single Electrical Control Solenoid Valve DC 24V For Automation
A solenoid coil , armature , oring ,seals and alumium alloy valve body make a Pneumatic solenoid valve. Pneumatic solenoid valve as a control components of automation machine in industrial production, Widely used in intelligent and wireless equipment.
Product Features:
1. High-strength aluminum alloy botton cover 2. One-time machining of valve lever by CNC, high precision
3. Valve body was machining by CNC, clean and beautifull
4. spacial processing of inner hole, small friction resistance and low starting pressure
5. High-precision pilot accessories, excitation time of only 0.05 seconds
6. imported seals, the life up to 10 millions of times
7. Aluminum alloy piston is not easy to damage
8. Embedded copper nut not easy to loose
9. with a manual device for installaton and testing
10. Copper coil has avariety of voltage available for selection
Youtube Video of Single Air Control Solenoid Valve:
Dimension of 4V Series 1/4'' Pneumatic Solenoid Valve:
Technical Data:
Model
|
4V210-06
4V220-06
|
4V230C-06
4V230E-06
4V230P-06
|
4V210-08
4V220-08
|
4V230C-08
4V230E-08
4V230P-08
|
Fluid
|
Air(to be filtered by 40 μ m filter element)
|
|||
Acting
|
Internal pilot or external pilot
|
|||
Port Size
|
In=Out=Exhaust=1/8''
|
In=Out=1/4'' Exhaust=1/8''
|
||
Orifice Size
|
25.00 mm2 (Cv=0.78)
|
18.00 mm2 (Cv=0.67)
|
30.00 mm2 (Cv=0.89)
|
18.00 mm2 (Cv=0.67)
|
Valve Type
|
5 port 2 position
|
5 port 3 position
|
5 port 2 position
|
5 port 3 position
|
Operating Pressure
|
0.15~0.8MPa (21~114psi)
|
|||
Proof Pressure
|
1.5MPa (215psi)
|
|||
Temperature ℃
|
-20~70
|
|||
Material of Body
|
Aluminum alloy
|
|||
Max. frequency
|
5 cycle/sec
|
3 cycle/sec
|
5 cycle/sec
|
3 cycle/sec
|
Details:
Construction:
Part Name | Material |
Solenoid Coil | Copper Wire |
Armature | Brass and Stainless Steel |
Valve body | Stainless Steel |
Oring & Seal | NBR(common) |
Connector | Plastic |
Application :
How To Choose Directional Control Valve:
1.According to the type of control element to be controlled or the application area and occasion, the diameter and type of the selection valve .control double-acting cylinder to select four-way or five-way valve; control single-acting cylinder to select three-way valve; control various Select the two-way or three-way valve (such as steam valve or water valve) for fluid flow conversion.
2.According to the use occasion and environment.For automatic control, long-distance and complex control process, choose electric control valve (that is, solenoid valve)
3.According to the working voltage
4.According to the action type.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
