SCG353A043 3/4" Right Angle ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector

SCG353A043 3/4" Right Angle ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector

    • SCG353A043 3/4" Right Angle ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector
    • SCG353A043 3/4" Right Angle ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector
    • SCG353A043 3/4" Right Angle ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector
    • SCG353A043 3/4" Right Angle ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector
  • SCG353A043 3/4" Right Angle ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: SCG353A043

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Port Size: G3/4'' Nonimal Diameter: φ20
    Valve Type: Right Angle Connection Type: Threaded
    Media: Air Working Pressure: 0.3~0.8Mpa
    Voltage: AC220V, AC110V, AC24V, DC24V

    SCG353A043 3/4'' ASCO Type Integral Pilot Operated Pulse Valve For Reverse Dust Collector



    These valves are specifically developed for filter cleaning of dust collectors and baghouses in reverse pulse jet systems. Those applications require high peak pressure, high flow rates, long life, and extremely fast valve opening and closing for effective filter cleaning while minimizing compressed air waste. When considering pulse valve characteristics, key attributes sought alike include robust performance, reliability, and ease of use. Today’s more popular pulse valves on the market offer users a simplified design that helps to maximize valve performance, translating into longer system uptimes. For the functional design of a pulse valve, there are multiple connection options, including threaded, dresser, and even a quick-mount option that enables faster, easier, and more secure installation.



    Youtube Video of SCG353A043 Right Angle Pneumatic Pulse Valve:



    Technical Data:

    Model No SCG353A043
    Port Size  G 3/4 Inch
    Nornimal Size Φ20
    Working Pressure  0.3~0.8Mpa
    Working Temperature  -5~+55℃
    Relative Humidity  ≤85%
    Working Medium  Air
    Protection Class  IP65
    Service Life  Over 1000000 times
    Voltage  AC220V, AC110V, AC24V, DC24V



    Dimension of SCG353A043 Dust Collector Pulse Valve:

    Dimension of SCG353A043 Dust Collector Pulse Valve:





    Details About SCG353A043 Pilot Operated Solenoid Pusle Valve:

    Details About SCG353A043 Pilot Operated Solenoid Pusle Valve:



    Features of ASCO Type 353 Series Pulse Valve:

    ​​​​​​​​​​​​​​​​​Specially designed for reverse jet-type dust collector systems
    High flow Cv(s) to 140 for effective bag cleaning
    High cycle life and fast opening/closing
    High quality polyacetal (POM) piston cartridge provides a long operating life and a large temperature range
    Quick mount connection eliminates thread cutting and sealing
    Integral operators have molded epoxy coils, with available options
    Valves may be mounted in any position



    Application of ASCO Type Solenoid Pulse Valve:

    The ASCO Type Dust Collector Series are high-flow fast-opening 2-way valves, pilot valves, pilot valve enclosures, and bulkhead fittings that have been specially designed for use in dust collector systems.

    Concrete Processing
    Grain, Agriculture and Feed
    Metal Working (Abrasive Blasting)
    Food Processing
    Foundries
    Pharmaceutical



    Construction:
    Body and Dreeser Nuts: Aluminum (diecast)
    Ferrule: 305 Stainless Steel
    Armature: 430FR Stainless Steel
    Diaphragm and Seals: Nitrile or FKM
    Spring: 304 Stainless Steel
    Screws: 302 or 304 Stainless steel

    Diaphragm Seat: PA-66 (25 & 40MM standard), Nitrile-coated mild steel (76MM standard), Acetal (102MM standard) or FKM coated mild steel
