NBR Diaphragm Repair Kit For SBFEC 3/4" DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 Valves

NBR Diaphragm Repair Kit For SBFEC 3/4" DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 Valves

NBR Diaphragm Repair Kit For SBFEC 3/4" DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 Valves
video
NBR Diaphragm Repair Kit For SBFEC 3/4" DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 Valves
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D20A
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Diaphragm Repair Kit Mounting Hole Size: φ6.4mm
Diaphragm Material: NBR (Nitrile) Diaphragm OD: φ80mm
Center Distance: φ66mm Seat Material: NBR (Nitrile)
Seat OD: φ40mm Seat ID: φ18mm
Bleed Hole: 1 Spring: 1
Packaging: Individual Plastic Bag Sealed Suitable Valves: DMF-Z-20, MF-Z-20, DMF-ZM-20, MF-ZM-20
High Light:

pneumatic valve diaphragm

,

rubber diaphragm

NBR Diaphragm Repair Kit For SBFEC 3/4'' DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 Valves



This is replacement diaphragm kits for the SBFEC 3/4'' DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 pulse valves. This kit includes the standard wearing parts of the valve for field replacement.



By registering for a customized catalog, Brando offers a fast and easy way to order your replacements parts. We'll take your system specifications and create a catalog based on your system making it a breeze to find the right products for your installation.



We offer competitive accessories and replacement parts for dust collectors as following:

1. Pulse Controller
2. Diaphragm Valves
3. Repair Kits (Solenoid Coil, Armature Assembly, Diaphragms)



YouTube video of SBFEC Type 3/4'' NBR Diaphragm Valve Repair Kit:



Main dimension of SBFEC Replacement Nitrile Diaphragm Repair Kits:

NBR Diaphragm Repair Kit For SBFEC 3/4" DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 Valves 0



Details display of DMF/MF-ZM-20 DMF/MF-Z-20 Diaphragm Valve Kit:

NBR Diaphragm Repair Kit For SBFEC 3/4" DMF-Z-20 MF-Z-20 DMF-ZM-20 MF-ZM-20 Valves 1



Available Models of SBFEC Type DMF/MF Diaphragm Valve Repair Kits:

Ordering Code
Fitted Valve Code
Port Size
DTY
MF/DMF-T-25S, MF/DMF-T-40S, MF/DMF-T-50S, MF/DMF-T-62S,
MF/DMF-ZM-40S, MF/DMF-Y-40S, MF/DMF-Y-50S, MF/DMF-Y-62S,
MF/DMF-Y-76S, MF/DMF-YA-76S, MF/DMF-YB-76S, MF/DMF-Y-102S,
MF/DMF-Y-102SA, MF/DMF-Y-102SE, MF/DMF-ZF-40S, MF/DMF-Z-40S,
MF/DMF-Z-50S, MF/DMF-Z-62S, MF/DMF-Z-76S, MF/DMF-Z-102S
Tip: Secondary Diaphragm
D20A
DMF-Z-20, MF-Z-20, DMF-ZM-20, MF-ZM-20
3/4''
D25
DMF-Z-25, MF-Z-25, DMF-ZM-25, MF-ZM-25,
DMF-ZF-25, MF-ZF-25, DMF-Y-25, MF-Y-25,
DMF-T-20, MF-T-20
3/4'' & 1''
D40
DMF-Z-40S, MF-Z-40S, DMF-Y-40S, MF-Y-40S,
DMF-ZF-40S, MF-ZF-40S, DMF-ZM-40S, MF-ZM-40S,
DMF-T-25S, MF-T-25S
1'' & 1-1/2''
D50
DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S,
DMF-T-50S, MF-T-50S
2''
D62
DMF-Z-62S, MF-Z-62S, DMF-Y-62S, MF-Y-62S
2-1/2''
D76
DMF-Z-76S, MF-Z-76S, DMF-Y-76S, MF-Y-76S
3''
D102
DMF-Z-102S, MF-Z-102S, DMF-Y-102S, MF-Y-102S
4''
D102A
DMF-Y-102SA, MF-Y-102SA
4''
DZL-20B
DMF-ZL-B, MF-ZL-B
3/4''

Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12
