K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit For 2" CA/RCA50T 2 1/2" CA/RCA62T Diaphragm Valve

K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit For 2" CA/RCA50T 2 1/2" CA/RCA62T Diaphragm Valve

    • K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit For 2" CA/RCA50T 2 1/2" CA/RCA62T Diaphragm Valve
    • K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit For 2" CA/RCA50T 2 1/2" CA/RCA62T Diaphragm Valve
  • K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit For 2" CA/RCA50T 2 1/2" CA/RCA62T Diaphragm Valve

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: K5004

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiation
    Packaging Details: Plastic Bags, Cartons, Pallet
    Delivery Time: 4-7 Days
    Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
    Supply Ability: 200000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: K5004 M1638A Buna Diaphragm Kit Mounting Hole Size: 8.5mm
    Diaphragm Material: Buna (Nitrile) Diaphragm OD: 183mm
    Seat Material: Buna (Nitrile) Seat OD: 103mm
    Seat ID: 50mm Bleed Hole: 1
    Spring: 2 Packaging: Individual Plastic Bag Sealed
    Suitable Valves: 2'' CA50T & RCA50T, 2 1/2'' CA62T & RCA62T
    High Light:

    Goyen Diaphragm

    ,

    Goyen Pulse Valve Diaphragm

    ,

    Goyen Diaphragm Repair Kit

    K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit

    This is K5004 M1638A buna diaphragm kit, used in Goyen 2'' CA50T & RCA50T, 2 1/2'' CA62T & RCA62T diaphragm valves. Because the diaphragm of pulse valve is a flexible mechanism which needs to open and close frequently to control the air flow, it requires good flexibility and as high sealing as possible.

    Working Principle: When different pressure (or force) acts on both sides of the diaphragm of the pulse valve, the diaphragm moves to the lower side of the pressure, resulting in the displacement of the center of the diaphragm.

    Applications: The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.

    YouTube video of K5004 M1638A Goyen Type Buna Diaphragm Kit:


    Main dimension of Goyen Type K5004 M1638A Diaphragm Repair Kits:
    K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit For 2" CA/RCA50T 2 1/2" CA/RCA62T Diaphragm Valve 0

    Details display of CA/RCA50 CA/RCA62 Diaphragm Valve Repair Kit:
    K5004 M1638A Goyen Type Buna Diaphragm Valve Repair Kit For 2" CA/RCA50T 2 1/2" CA/RCA62T Diaphragm Valve 1

    Available Models of Goyen Type Buna/Buna Diaphragm Repair Kits:

    Valve Model Series Note Pipe Size Repair Kit
    CA/RCA20 DD, T * 3/4'' K2002 (M764)
    CA/RCA25 DD, FS, MM, T * 1'' K2502 (M736)
    CA/RCA32 * 1 1/2'' K2522 (M736)
    CA/RCA35 T * 1 1/2'' K3502 (M1591)
    CA/RCA40 DD, MM * 1 1/2'' K3502 (M1591)
    CA/RCA45 DD, FS, T *** 1 1/2'' K4504 (M2187)
    CA/RCA50 T

    ***

    1B

    2'' K5004 (M1638A)
    CA/RCA50 T

    ***

    3B

    2'' K5004 (M1638A)
    CA/RCA62 T

    ***

    1B

    2 1/2'' K5004 (M1638A)
    CA/RCA62 T

    ***

    3B

    2 1/2'' K5005 (M1639A)
    CA/RCA76 MM, T

    ***

    3B

    3'' K7600
    CA/RCA76 MM, T

    ***

    LP

    3'' K7604
    CA/RCA76 MM, T

    ***

    1B LP

    3'' K7610
    CA/RCA102 MM *** 4'' K10203
    CA/RCA8 MM *** 8'' K8000



    * Single Valve
    ** Older version with Single Valve
    *** Double Valve
    1B 1 Bleed Hole
    3B 3 Bleed Holes
    LP Low Pressure



    Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.



    Factory Production Pictures of Solenoid Valve Diaphragm Kits:

    34

    12


    The diaphragm consists of one or more layers coated on both sides. Diaphragms of different materials can be manufactured according to the requirements of use. The working temperature and pressure range of the diaphragm itself depends on the type of rubber, fabric and structure. The diaphragm can work at -10~80℃, 0.4~0.8 MPa, and the fluororubber and silicone rubber diaphragm can work at -80~232℃.
