K4504 M2187 Goyen Type Buna Diaphragm Repair Kit For 1 1/2" CA/RCA45T CA/RCA45DD CA/RCA45FS Pulse Valve

K4504 M2187 Goyen Type Buna Diaphragm Repair Kit For 1 1/2" CA/RCA45T CA/RCA45DD CA/RCA45FS Pulse Valve

    • K4504 M2187 Goyen Type Buna Diaphragm Repair Kit For 1 1/2" CA/RCA45T CA/RCA45DD CA/RCA45FS Pulse Valve
    • K4504 M2187 Goyen Type Buna Diaphragm Repair Kit For 1 1/2" CA/RCA45T CA/RCA45DD CA/RCA45FS Pulse Valve
  • K4504 M2187 Goyen Type Buna Diaphragm Repair Kit For 1 1/2" CA/RCA45T CA/RCA45DD CA/RCA45FS Pulse Valve

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: K4504

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiation
    Packaging Details: Plastic Bags, Cartons, Pallet
    Delivery Time: 4-7 Days
    Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
    Supply Ability: 200000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: K4504 M2187 Buna Diaphragm Kit Mounting Hole Size: 7mm
    Diaphragm Material: Buna (Nitrile) Diaphragm OD: 124mm
    Seat Material: Buna (Nitrile) Seat OD: 68mm
    Seat ID: 31.5mm Bleed Hole: 1
    Spring: 2 Packaging: Individual Plastic Bag Sealed
    Suitable Valves: CA45T, RCA45T, CA45DD, RCA45DD, CA45FS, RCA45FS
    High Light:

    Goyen Diaphragm

    ,

    Goyen Pulse Valve Diaphragm

    ,

    Goyen Diaphragm Repair Kit

    K4504 M2187 Goyen Type Buna Diaphragm Repair Kit

    This is K4504 M2187 buna diaphragm kit, used in Goyen 1 1/2" CA45T, RCA45T, CA45DD, RCA45DD, CA45FS, RCA45FS diaphragm valves. One set of K4504 M2187 diaphragm kit includes one buna seat buna diaphragm and one small stainless steel spring. The diaphragm is the key component in diaphragm pulse jet valves. It is one of the fittings for the normal operation of the valve body and the "switch" of the injection air circuit of the dust cleaning system of the pulse bag filter. It can easily ensure complete synchronization with other control components to control the injection of pulsed compressed air. So the tightness and softness of the diaphragm play a decisive role in the blowing effect of the pulse valve.

    YouTube video of K4504 M2187 Goyen Type Buna Diaphragm Kit:


    Main dimension of Goyen Type K4504 M2187 Diaphragm Repair Kits:
    K4504 M2187 Goyen Type Buna Diaphragm Repair Kit For 1 1/2" CA/RCA45T CA/RCA45DD CA/RCA45FS Pulse Valve 0

    Details display of K4504 CA/RCA45 Diaphragm Valve Repair Kit:
    K4504 M2187 Goyen Type Buna Diaphragm Repair Kit For 1 1/2" CA/RCA45T CA/RCA45DD CA/RCA45FS Pulse Valve 1

    Available Models of Goyen Type Buna/Buna Diaphragm Repair Kits:

    Valve Model Series Note Pipe Size Repair Kit
    CA/RCA20 DD, T * 3/4'' K2002 (M764)
    CA/RCA25 DD, FS, MM, T * 1'' K2502 (M736)
    CA/RCA32 * 1 1/2'' K2522 (M736)
    CA/RCA35 T * 1 1/2'' K3502 (M1591)
    CA/RCA40 DD, MM * 1 1/2'' K3502 (M1591)
    CA/RCA45 DD, FS, T *** 1 1/2'' K4504 (M2187)
    CA/RCA50 T

    ***

    1B

    2'' K5004 (M1638A)
    CA/RCA50 T

    ***

    3B

    2'' K5004 (M1638A)
    CA/RCA62 T

    ***

    1B

    2 1/2'' K5004 (M1638A)
    CA/RCA62 T

    ***

    3B

    2 1/2'' K5005 (M1639A)
    CA/RCA76 MM, T

    ***

    3B

    3'' K7600
    CA/RCA76 MM, T

    ***

    LP

    3'' K7604
    CA/RCA76 MM, T

    ***

    1B LP

    3'' K7610
    CA/RCA102 MM *** 4'' K10203
    CA/RCA8 MM *** 8'' K8000



    * Single Valve
    ** Older version with Single Valve
    *** Double Valve
    1B 1 Bleed Hole
    3B 3 Bleed Holes
    LP Low Pressure



    Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.



    Factory Production Pictures of Solenoid Valve Diaphragm Kits:

    34

    12


    Diaphragm Features:


    1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.



    2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.



    3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.



    4. Facbric-reinforced diaphragms advantages:
    * No leakage * No Lubrication * No Breakaway Force * No Friction
    * Functionality Over Wide Pressure Ranges
    * High Strength * Low Cost * Simple Design * Versatility



    5. EPDM, Viton all available.



    Focus on your demands, Offer you best solution:



    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing



    Welcome to your any question and inquiry!
