Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit For 3/4" CA/RCA20T CA/RCA20DD Valves

Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit For 3/4" CA/RCA20T CA/RCA20DD Valves

    • Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit For 3/4" CA/RCA20T CA/RCA20DD Valves
    • Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit For 3/4" CA/RCA20T CA/RCA20DD Valves
  • Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit For 3/4" CA/RCA20T CA/RCA20DD Valves

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: K2000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiation
    Packaging Details: Plastic Bags, Cartons, Pallet
    Delivery Time: 4-7 Days
    Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
    Supply Ability: 200000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: K2000 M1204B RCA20 Diaphragm Kit Mounting Hole Size: 8.5mm
    Diaphragm Material: Buna (Nitrile) Diaphragm OD: 74mm
    Center Distance: 74mm Seat Material: Buna (Nitrile)
    Seat OD: 40mm Seat ID: 17.5mm
    Air Hole: With Spring: With
    Packaging: Individual Sealed Suitable Valves: RCA20T, RCA20DD
    High Light:

    Goyen Diaphragm

    ,

    Goyen Pulse Valve Diaphragm

    ,

    Goyen Diaphragm Repair Kit

    Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit With Rubber Seat



    This is K2000 M1204B RCA20 Buna Diaphragm Kit includes one buna seat buna diaphragm and one 304 stainless steel spring, which is used in RCA20T, RCA20DD pulse jet valves. The diaphragm consists of one or more layers coated on both sides. Diaphragms of different materials can be manufactured according to the requirements of use. The working temperature and pressure range of the diaphragm itself depends on the type of rubber, fabric and structure. The diaphragm can work at -10~80℃, 0.4~0.8 MPa, and the fluororubber and silicone rubber diaphragm can work at -80~232℃.



    YouTube video of Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit:



    Main dimension of Goyen Type K2000 M1204B Diaphragm Repair Kits:

    Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit For 3/4" CA/RCA20T CA/RCA20DD Valves 0



    Details display of K2000 Goyen Type CA/RCA20 Diaphragm Valve Repair Kit:

    Goyen Type K2000 M1204B RCA20 Buna Diaphragm Kit For 3/4" CA/RCA20T CA/RCA20DD Valves 1



    Available Models of Goyen Type CA/RCA/RCAC Diaphragm Valve Repair Kits:

    Models Material Available Valve
    K2000 Buna (R)CA20T, DD
    K2007 Viton/Viton (R)CA20T, DD
    K2003 Buna/Nylon (R)CA20M
    K2004 Viton/Viton (R)CA20M
    K2017 Buna/Nylon (R)CAC20 (Millennium)
    K2016 Viton/Viton (R)CAC20 (Millennium)
    K2034 Shockwave (R)CAC20T4, ST4, DD4, FS4
    K2033 Viton/PTFE (R)CAC20T4, ST4, DD4, FS4

    Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.



    Factory Production Pictures of Solenoid Valve Diaphragm Kits:

    34

    12



    Brief introduction of K2000 M1204B Diaphragm Kit:

    K2000 diaphragm material is Nitrile (NBR), not suitable for strong solvents and chemical fluids, oil resistant. We use high quality material, the collection equipment efficiency can be improved, the energy loss also can be reduced. K2000 M1204B repair kit has unique geometric diaphragm design , high speed from multiple diaphragm to reach the highest peak in an instant.



    Working Principle: When different pressure (or force) acts on both sides of the diaphragm of the pulse valve, the diaphragm moves to the lower side of the pressure, resulting in the displacement of the center of the diaphragm.



    Applications: The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.



    Tips:
    1. Before conducting any maintenance activity on the system ensure that components are fully isolated from pressure and power supplies. Pressure and power should not be reapplied until the valve has been fully assembled.

    2. Diaphragm and pilot inspection should be conducted annually.
