Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCAC25FS3 Pulse Valves

Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCAC25FS3 Pulse Valves

    • Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCAC25FS3 Pulse Valves
    • Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCAC25FS3 Pulse Valves
  • Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCAC25FS3 Pulse Valves

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: K2529

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiation
    Packaging Details: Plastic Bags, Cartons, Pallet
    Delivery Time: 4-7 Days
    Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
    Supply Ability: 200000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: K2529 25 Millennium Buna Diaphragm Kit Diaphragm Material: Buna (Nitrile)
    Diaphragm OD: 93mm Seat Material: Nylon
    Seat OD: 46mm Seat ID: 28.5mm
    Air Hole: With Spring: With
    Packaging: Individual Sealed Suitable Valves: RCAC25T3, RCAC25DD3, RCAC25FS3
    High Light:

    Goyen Diaphragm

    ,

    Goyen Pulse Valve Diaphragm

    ,

    Goyen Diaphragm Repair Kit

    Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCACFS3 Pulse Valves

    This is K2529 25 millennium buna diaphragm kit, used in Goyen 1" RCAC25T3, RCAC25DD3, RCAC25FS3 diaphragm valves. One set of K2529 diaphragm kit includes one Nylon seat buna diaphragm and one small stainless steel spring. The diaphragm is the key component in diaphragm pulse jet valves. It is one of the fittings for the normal operation of the valve body and the "switch" of the injection air circuit of the dust cleaning system of the pulse bag filter. It can easily ensure complete synchronization with other control components to control the injection of pulsed compressed air. So the tightness and softness of the diaphragm play a decisive role in the blowing effect of the pulse valve.

    YouTube video of Goyen Type K2529 25 Millennium Buna Diaphragm Kit:


    Main dimension of Goyen Type K2529 25 Millennium Diaphragm Repair Kit:
    Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCAC25FS3 Pulse Valves 0

    Details display of K2529 Goyen Type RCAC25 Diaphragm Valve Repair Kit:
    Goyen Type K2529 25 Millennium Buna Diaphragm Kit For RCAC25T3 RCAC25DD3 RCAC25FS3 Pulse Valves 1

    Available Models of Goyen Type 1'' RCA/RCAC Diaphragm Valve Repair Kits:

    Models Material Available Valve
    K2500 Buna/Nylon (R)CA32
    K2501 Buna/Nylon (R)CA25
    K2502 Buna/Buna (R)CA25
    K2503 Viton/Viton (R)CA25
    K2529 Buna/Nylon (R)CAC25 (Millennium)
    K2530 Viton/Viton (R)CAC25 (Millennium)
    K2546 Shockwave (R)CAC25T4, ST4, DD4, FS4
    K2551 Viton/PTFE (R)CAC25T4, ST4, DD4, FS4
    K2552 Nitrile/HDPE (R)CAC25T4, ST4, DD4, FS4

    Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.


    Factory Production Pictures of Solenoid Valve Diaphragm Kits:

    34

    12



    Diaphragm Features:


    1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.



    2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.



    3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.



    4. Facbric-reinforced diaphragms advantages:
    * No leakage * No Lubrication * No Breakaway Force * No Friction
    * Functionality Over Wide Pressure Ranges
    * High Strength * Low Cost * Simple Design * Versatility



    5. EPDM, Viton all available.

    Tips:
    1. Before conducting any maintenance activity on the system ensure that components are fully isolated from pressure and power supplies. Pressure and power should not be reapplied until the valve has been fully assembled.

    2. Diaphragm and pilot inspection should be conducted annually.
