AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve

AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve

  • AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve
  • AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve
  • AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve
  • AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve
AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE, ISO
Model Number: SCG353A044
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiation
Packaging Details: PVC bag, inner box, canton, then packed by pallet
Delivery Time: One weeek after payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Model Number: SCG353A044 Port Size: 1 Inch
Material: Aluminum, SS304, Enamelled Wire Voltage: DC, AC All Available
Working Pressure: 0.4--0.6Mpa Working Life: More Than 1 Million Times
Temperature: -5℃ To +55℃ Application: Solenoid Valve
High Light:

ASCO Pulse Jet Valve

,

ASCO Dust Collector Valve

,

ASCO Pulse Diaphragm Valve

AC220V DC24V 1'' DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve



FEATURES:
• The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation
• The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for dust collector service applications
• The design with integral compression fittings will facilitate installation because there is no need for threaded piping
• The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions
• Integral pilot operated valves satisfy all relevant EC directives



1. The 3" dust collector pulse diaphragm pulse valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to provide reliable and economical operation
2. The high flow, angle type bodies in combination with the special main diaphragm
assemblies give the unique operating features required for dust collector service applications3.The design with integral compression fittings will facilitate installation because there is no need for
threaded piping
3. The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life,
even under harsh conditions



ASCO Type Series Model Specification:

Model NO. SCG353A043 SCG353A044 SCG353A047 SCG353A050 SCG353A051
Port Size G3/4'' G1'' G1-1/2'' G2'' G2-1/2''
Normal Size φ20mm φ25mm φ40mm φ50mm φ62mm
Working Pressure 0.3 to 0.8MPa
Environment Temperature -5 to +55℃
Relative Humidity ≤85%
Operating Medium Dry clean compressed air
Service Life Over one million times
Voltages AC24V, AC110V, AC220V, DC24V



Overall Dimensions of ASCO Pulse valve

AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve 0

ASCO Type Electromagnetic Pulse Valve Detail:

AC220V DC24V 1" DN25 Threaded Port NBR Diaphragm Aluminum Body SCG Series SCG353A044 Pulse Jet Valve 1

Tips: All accessories can be sold separately as repair parts (Diaphragm, Solenoid Coil, Armature Assembly)



Pulse Valve Internal Structure and Main Parts:

Part Name Material
Solenoid coil high quanlity enamelled wire
Armature assembly SS304, 430FR
Small common cap ADC aluminum
Diaphragm  NBR (nitrile, buna-n)
Top end cap ADC aluminum
Big spring SS304
Screws SS302
Seal NBR, Viton, all can be customized
Main body ADC aluminum



Advantages of ASCO pulse valve:

1, mainly designed for dust collecting application, with characteristic of high flow value, long working life and fast switch response, to ensure the steady function of dust removing system

2, the diaphragms with high quality and proffessional design for pulse valve working life



Youtube Video Of ASCO Type Solenoid Valve For Dust Collector:



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
