Name: BSPT 1/8" 4V130C-06 Airtac Type Pneumatic Solenoid Air Valve 5 Way 3 Position DC12V AC110V
Brand: Brando
SKU: 4V130C-06
Price: 3 USD
Availability: InStock
Rating: 4.9 (110 reviews)

Home Products Pneumatic Solenoid Valve

BSPT 1/8" 4V130C-06 Airtac Type Pneumatic Solenoid Air Valve 5 Way 3 Position DC12V AC110V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	4V130C-06

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	$3 to $7 per pc
Packaging Details:	Inner box, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Product Name:	4V130C-06 AirTAC Type Pneumatic Solenoid Valve	Ports:	Air Inlet=Air Outlet=Exhaust=1/8"
Body Material:	Aluminum Alloy	Positions:	5 Way 3 Position
Working Media:	40 Micron Filtered Air	Motion Pattern:	Inner Guide Type
Operating Pressure:	0.15-0.8 MPa / 22-116 PSI	Operating Temperature:	-5 To + 50ºC / 41-122ºF
Wiring Form:	Lead Wire Or Connector Type	Insulation And Protection:	Class F Class / IP65
Voltages:	DC24V, DC12V, AC220V, AC110V
High Light:	electric solenoid valve , solenoid pneumatic valve

BSPT 1/8'' 4V130C-06 Airtac Type Pneumatic Solenoid Air Valve 5 Way 3 Position DC12V AC110V

The 4V130C-06 is a directional control pneumatic solenoid valve with a five way & three position (P = Pressure, A = Outlet, R = Exhaust for port A), which is same with Airtac brand. Five-way, three-position valves are generally used to fully extend a double acting (air return) cylinder, or in applications with similar operation. The center position can be configured as Closed Center (to passively stop a cylinder in its current position), Exhaust Center (to allow the cylinder to freely move, i.e. be hand-adjusted), or Pressure Center (to actively stop a cylinder in its current position, with pressure on both ends).

YouTube video of 1/8'' 4V130C-06 AirTAC Type Pneumatic Solenoid Valve:

Main dimension of G1/8'' 4V130C-06 Airtac Type 5/3 Way Solenoid Valve:

BSPT 1/8" 4V130C-06 Airtac Type Pneumatic Solenoid Air Valve 5 Way 3 Position DC12V AC110V 0

Details enlargement of 4V130C-06 5 Way 3 Position Solenoid Air Valve:

BSPT 1/8" 4V130C-06 Airtac Type Pneumatic Solenoid Air Valve 5 Way 3 Position DC12V AC110V 1

Technical data of 4V Series Aluminum Alloy Pneumatic Solenoid Valves:

Model	4V110-06 4V120-06	4V130C-06 4V130E-06 4V130P-06	4V110-08 4V120-08	4V130C-08 4V130E-08 4V130P-08
Fluid	40 Micron Filtered Air
Operation	Internal pilot or external pilot
Ports Size	In=Out=1/8''		In=Out=1/4''
Orifice Size	5.5 mm² (Cv=0.31)	5.0 mm² (Cv=0.28)	12.00 mm² (Cv=0.67)	9.00 mm² (Cv=0.50)
Valve Type	5 Way 2 Position	5 Way 3 Position	5 Port 2 Position	5 Way 3 Position
Operating Pressure	0.15 to 0.8MPa (21 to 114psi)
Proof Pressure	1.5MPa (215psi)
Operating Temperature	-5 to 50 ℃
Body Material	Aluminum Alloy
Max. Frequency	5 cycle/sec	3 cycle/sec	5 cycle/sec	3 cycle/sec

Factory Production display of 4V Series Pneumatic Solenoid Valves:

Features:
1. Pilot mode: internal pilot or external pilot.
2. Sliding column structure: good sealing and sensitive response.
3. The three-position solenoid valve has three central functions for you to choose from.

4. The dual-control solenoid valve has a memory function.
5. The inner hole adopts special processing technology, which has low friction and wear, low starting pressure and long service life.
6. It can form an integrated valve group with the base to save installation space.
7. Equipped with attached manual equipment to facilitate installation and commissioning.
8. Several standard voltage levels are optional.
