| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | DMF-Y-40S |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Body Material: | Aluminum Alloy | Seal Material: | NBR, HNBR, FKM, EPDM, Can Be Customized |
|---|---|---|---|
| Structure: | Diaphragm | Number Of Diaphragm: | 2 |
| Diaphragm Material: | NBR | Port Size: | G 1-1/2'' |
| Application: | Bag Dust Collector System | ||
| High Light: | BFEC Pulse Valve,BFEC Diaphragm Valve,BFEC Solenoid Valve |
||
Aluminum Body DMF-Y-40S 1-1/2'' Threaded Port Diamphragm Valve For Bag Dust Collector System
The DMF-Y solenoid/diaphragm valve is kind of submerged valve (namely, insert valve), which is installed directly on a secondary gas bag and achieves better circulation quality. The valve has less pressure loss, and is applicable to the operations with lower gas pressure.
DMF-ZM-40S die casting aluminum body and the seals and diaphragm can be custmized .Widely used in industrial bag dust removal filter.
Odering Code:
| DMF | Y | X | S | X |
| Solenoid Diaphragm valve | Embedded | Diameter | Double Diaphragms | Temperature Lever |
Technical Data of Submerged Pulse Jet Valve DMF-Y-40S For Industrial Bag Filters Dedusting:
| Type | DMF-Y-40S |
| Diameter(mm) | Φ40 |
| Diameter(Inch) | G1-1/2'' |
| Number of diaphragm | 2 |
| Outlet orifice connection | G1-1/2'' |
| KV | 47.36 |
| CV | 55.27 |
| TEMP | -25℃ to +80℃ or customized |
| Working Media | Air |
| Voltage | AC110V, AC220V, DC24V |
Overall Dimension of 1-1/2 Inch Double Diaphragm Pulse Jet Valve:
Material Construction:
| Part | Material |
| Coil | Copper |
| Body | Die Casting Aluminum ADC12 |
| Armature | 430FR Stainless Steel |
| Diaphragm & Seals | NBR, HNBR, FKM, EPDM, Silicone, All Available |
| Spring | 321 Stainless Steel |
| Screws | 302 Stainless Steel |
Installation Diagram
Details About Submerged Pneumatic Pulse Valve DMF-40S
More Details About DMF Pulse Solenoid Valve Embedded BFEC Type On Youtube:
Installation:
1. Prepare supply and blowtube pipes to suit valve specification. Avoid installing valves underneath the tank.
2. Ensure tank and pipes are free from dirt, rust or other particulate.
3. Ensure supply air is clean and dry.
4. Mount valves to inlet pipes and blowtube to valves, ensuring no excess thread sealant can enter the valve itself.
5. Make electrical connections to solenoid.
6. Apply moderate pressure to system and check for installation leaks.
7. Fully pressurise system.
8. Test fire and listen for proper actuation and crisp pulse noise.
Maintenance:
1. Before conducting any maintenance activity on the system ensure that components are fully isolated from pressure and power supplies.
2. Pressure and power should not be reapplied until the valve has been fully assembled.
3. Diaphragm and pilot inspection should be conducted annually.
Features
1.With aluminum die casting, small volume and fine appearance.
2.The required components are all processed by CNC machine tools to ensure the accuracy and reliability of the solenoid valve.
3.The use of the novel and ingenious piston structure makes the principle more scientific, long life.
4.Seals , Diaphragm and Voltage can be customized.
Welcome to your any question and inquiry!
Contact Person: Mia
Tel: +8613454729544
