RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle

RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle

    • RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle
    • RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle
    • RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle
    • RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle
  • RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: RVH000095

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: $5-$10 per set
    Packaging Details: Inner Box, Carton, Pallet
    Delivery Time: 4-8 days
    Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
    Supply Ability: 50000 sets per month
    Contact Now
    Detailed Product Description
    Name: RVH000095 Air Suspension Solenoid Valve Coil Hole Size: φ9.1mm
    Hole Depth: 28mm Hole Number: 3
    Terminals: 6 Pins Normal Voltage: DC12V
    Resistant: 2.1Ω Shell Material: Polyamide 66
    Function: Air Suspension Valve Block Solenoid Coil Fitment: Land Rover Range Rover Sport 2006-2013, Land Rover LR3 2005-2009, Land Rover LR4 2010-2015

    RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle



    Applicaiton: Front Air Suspension Valve Block RVH000095 For Land Range Rover Sport LR3 LR4.

    Fitments (Please Compare The Part Number With Your Original One Before Purchasing):
    1. Range Rover Sport 2006-2013
    2. Land Rover Discovery 3/LR3 2005-2009
    3. Land Rover Discovery 4/LR4 2010-2015



    The solenoid coil is used for the Range Rover L322 / LM air supply system to control the compressed air reservoir and the height of the air suspension. It offers you maximum security, accuracy, quality and durability as the important part.



    Main dimension of RVH000095 Air Suspension Solenoid Coil For Land Rover LR3 LR4:

    RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle



    Technical data of Solenoid Coil For RVH000095 Range Rover Sport Front Valve Bolck:

    Terminal 6 Pins
    Normal Voltage DC12V
    Normal Resistant 2.1Ω
    Insulation class F, H
    Connection type Deutch
    Fitments 1. Range Rover Sport 2006-2013
    2. Land Rover Discovery 3/LR3 2005-2009
    3. Land Rover Discovery 4/LR4 2010-2015
    Application Front Air Suspension Valve Block RVH000095



    Details of Land / Range Rover RVH000095 Air Suspension Solenoid Valve Coil:

    RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle



    Applied in RVH000095 Air Suspension Front Axle EAS Solenoid Valve Block:

    RVH000095 Air Suspension Solenoid Valve Coil For Land / Range Rover Sport LR3 LR4 Front Axle



    Video display of Air Suspension Front Axle Transfer Relief Valve Coil in Youtube:



    Features of RVH000095 Air Suspneison EAS Valve Block Solenoid Coil:
    1. Mechanical properties: high strength, fatigue resistance, stable size and small creep.
    2. Aging resistance: The enhanced UL temperature index reaches 120~140 °C. Solvent resistance: no stress cracking.
    3. With OE number of RVH000095, RVH000055.
    4. Excellent chemical stability, mechanical strength, electrical insulation and thermal stability.
    5. Fits for Land Rover LR3 LR4 Range Rover Sport.



    FAQ:

    1. Are you a factory or trading company?

    We are a factory, and OEM/ODM is available.



    2. Is sample order acceptable?
    Yes.It's ok.



    3. What is the minimum order quantity?

    The MOQ is 1 piece.



    4. Where are your markets reaching throughout the world?

    We have established long-term relationships with customers from Russia, India, America, Australia, South Africa, etc.



    5. what’s your main products?

    Our main products include kits for automobile systems such as injector rail, solenoid valve, solenoid coil, armature assembly, etc.



    6. Do you have the ability to do independent research and development?

    We have developed our own patented products. And we are trying to perfect our products.



    7. If I have a suggestion that I would like to provide,how could I contact with you?

    Please directly call us, email us or get in touch with us by whatsapp.



    8. Do you test all your goods before delivery?

    Yes, we have 100% test before delivery and test equipment is professional.



    Focus on your demands, Offer you best solution:

    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing



    Welcome to your any question and inquiry!
