SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V

SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V

  • SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V
  • SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V
  • SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V
  • SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V
SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V
Product Details:
Place of Origin: CHINA NINGBO
Brand Name: BRANDO
Certification: CE,ISO,GB
Model Number: DMF-Y-76S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: 4-10 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 150000 pieces per month
Contact Now
Detailed Product Description
Name: SBFEC Type DMF-Y-76S Pulse Valve Valve Type: Full Immersion (Embedded)
Pipe Size: 3 Inch Connection: Female Thread (G)
Nominal Size: 76mm No Of Diaphragm: 2
Diaphragm & Seals Material: NBR Working Pressure: 0.1 To 0.8MPa
Working Temperature: -25 To +80℃ Voltages: AC24V, AC110V, AC220V, DC24V
High Light:

SBFEC Pulse Valve

,

SBFEC Solenoid Valve

,

SBFEC Diaphragm Valve

SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V


Brando offers a complete line of competitively priced “right angle”, “straight through” and “immersion” valve technology, and growing.

The follwing is DMF-Y-76S SBFEC type replacement full immersion diaphragm valve for bag filter.



1. Port Size: 3''
2. Connection Type: Threaded
3. Nonimal Diameter: φ76mm
4. Body Material: Aluminum ADC12
5. Voltages: DC24V, AC110V, AC220V, AC230V
6. Diaphragm Material: Nitrile (Common), VITON (Available)
7. Pilot type: Integral Solenoid Pilot
8. Working Pressure: 0.1 to 0.8 MPa
9. Environment Temperature: -25℃ to 80℃



YouTube video of DMF-Y-76S SBFEC Type Manifold Flat Mount Pulse Valve:



Overall Dimension of DMF-Y-76S SBFEC Type Full Immersion Pulse Valve:
SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V 0



Product details of SBFEC Type DMF-Y-76S Embedded Pulse Solenoid Valve:

SBFEC Type DMF-Y-76S G3'' Full Immersion Pulse Valve Manifold Mounted For Bag Filter DC24V 1


Technical parameter of SBFEC Type Manifold Flat Mount Pulse Jet Valves:

Model number
DMF-Y-25
DMF-Y-40S
DMF-Y-50S
DMF-Y-62S
DMF-Y-76S
DMF-Y-102S
Port sizes
G1''
G1 1/2''
G2''
G2 1/2''
G3''
G4''
Membrane sizes
(φ66 smaller)
φ96
φ112
φ160
φ188
φ202
φ255
CV values
30.53
53.47
71.47
150.85
186.66
313.09
Blowing area
(m2)
8-10
12-16
18-28
27-38
37-65
70-90
Weight
(kg)
0.75
1.2
2.35
3.2
4.05
5.65
Environment Temperature
-25℃ to +80℃
Relative Humidity
≤85%
Working Medium
Compressed Air
Protection Class
IP65
Service Life
Over one million times
Voltage
DC24V, AC24V, AC110V, AC220V

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm, Solenoid Coil and Armature Assembly.



The following are common faults and treatments:
1. The spring is damaged. The spring on the pulse valve spool is easily damaged. The appearance is that the pulse valve is deflated to the blow port for a long time. The treatment method is to replace the spring.


2. The rubber pad is damaged. After the use time is long, the rubber pad on the pulse valve spool is easily damaged. The appearance is that the pulse valve is deflated to the nozzle for a long time. The treatment method is to replace the rubber pad.


3. The valve core dirt, because the intake air is not clean, causing the fouling of the valve core, resulting in the appearance of the long-term intake of the blow port or the pulse valve does not work after the power, the treatment method is to clean the valve core.


4. The diaphragm is damaged, after long-term work, the diaphragm is easy to fatigue, oxidation, etc., the appearance is the long-term deflation of the pressure relief port, the pulse valve does not work, the treatment method is to replace the diaphragm.


5. The orifice is blocked or damaged. The intake air is not clean and the throttle hole is blocked. The appearance is that the pulse valve is deflated to the nozzle for a long time. The treatment method is to clean the orifice; the orifice is damaged or missing, and the orifice is made. Loss of interception, resulting in abnormal pressure relief, the appearance is that the pulse valve has action after the power is turned on, the pressure relief port is deflated, but the pulse valve is not sprayed, the treatment method is a replacement throttle.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
