DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V

DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V

    • DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V
    • DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V
    • DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V
  • DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V

    Product Details:

    Place of Origin: CHINA
    Brand Name: BRANDO
    Certification: CE,GB,ISO
    Model Number: DMF-Z-40S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Inner Box, Cartons, Pallet
    Delivery Time: 4-7 days
    Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
    Supply Ability: 100000 pieces per month
    Contact Now
    Detailed Product Description
    Name: SBFEC Type DMF-Z-40S Solenoid Valve Port Size: 1 1/2''
    Orifice Size: 40mm Connection: Thread
    Actuator: Integral Pilot Operated Pressure: 0.1MPa~0.8MPa
    Voltage: DC24V, AC220V, AC110V Membrane Material: Nitrile
    No Of Membrane: 2 Body Material: Aluminum Die-casting

    DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V



    DMF-Z-40S Solenoid Pulse Valve is an important spare part of pulse dust collector. It can be said that it is the core part. It is responsible for the cleaning effect of the entire bag filters.



    The working principle of the DMF-Z-40S electromagnetic pulse valves: the electric control instrument inputs the electric signal, so that the integral pilot head sucks the moving column, opens the unloading hole, the pressure gas in the back cavity of the diaphragm is quickly discharged, and the pressure gas in the front cavity of the diaphragm lifts the diaphragm. Open the pulse solenoid valve channel for blowing. The electric signal disappears, and the spring of the electromagnetic pilot head immediately resets the moving column to close the unloading hole. The gas pressure and the spring force of the diaphragm rear cavity close the channel, and the DMF-Z-40S pulse jet valve stops blowing. The damping hole on the diaphragm is used to dampen the airflow when the pilot head moves up and the gas pressure is unloaded. When the unloading is closed, the pressure gas is quickly filled into the rear cavity, so that the diaphragm closes the passage and stops blowing.



    YouTube video of 1 1/2'' SBFEC Type DMF-Z-40S Solenoid Valve:



    Main dimension of DMF-Z-40S 1 1/2'' SBFEC Replacement Pulse Valve:

    DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V



    Details enlargement of SBFEC Type DMF-Z-40S Diaphragm Valve:

    DMF-Z-40S 1 1/2 Inch SBFEC Type Solenoid Valve With Double Diaphragm For Dust Collector DC24V



    Technical data of SBFEC Replacement Right Angle Type Pulse Jet Valves:

    Model No. DMF-Z-20 DMF-Z-25 DMF-Z-40S DMF-Z-50S DMF-Z-62S DMF-Z-76S
    KV/CV values 17.55/20.48 26.16/30.53 45.82/53.47 61.24/71.47 129.26/150.85 159.95/186.66
    Blowing area 3.5-6 ㎡ 8-10 ㎡ 12-16 ㎡ 18-28 ㎡ 27-38 ㎡ 37-65 ㎡
    Inlet and Outlet Sizes 3/4'' 1'' 1 1/2'' 2'' 2 1/2'' 3''
    Weighgts 0.6 kg 0.75 kg 1.2 kg 2.35 kg 3.2 kg 4.05 kg
    Working pressure 1-8 bar
    Environment temperature -25-85℃
    Relative Humidity ≤85%
    Operating medium Compresed Clean Air
    Protection class IP 65
    Service lifes Over 1000000 times
    Voltages DC24V, AC110V, AC220V

    Tips: All related accessories are also sold, like Pulse Controller, Diaphragm, Solenoid Coil and Armature Assembly.



    Dust Collector Valve:

    A dust collector plays crucial role in various industries such as cement, steel, metal, gas etc. The major part of dust collector system is a dust collector valve that’s why dust collector Valves plays a vital role in any dust collection process, so performance and quality of valves are the major driving factor for all such industries.


    A variety of manufacturers make dust collector valve but cost- effectiveness, performance and quality are basic needs in every such product. What makes Brando unique is its exceptional quality, Low cost with fast delivery for guaranteed accessibility along with that continuous specialized support and administration, reliable operation and productive support.



    Focus on your demands, Offer you best solution:



    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing



    Welcome to your any question and inquiry!
