Exhaust Double Pilot Head Air Cylinder Valve / Solenoid Pneumatic Valve 4V230-08

1/4'' Air Inlet/outlet 1/8'' Exhaust Double Pilot Head Pneumatic Solenoid Valve 4V230-08

1, pneumatic device structure is simple, light, simple installation and maintenance. Medium for air, compared with the hydraulic medium is not easy to burn, so it is safe to use.

2, the working medium is inexhaustible air, air itself does not cost money. Exhaust treatment is simple, does not pollute the environment, low cost.

3. The adjustment of output force and working speed is very easy. The speed of the cylinder is generally less than 1M/S, which is faster than the hydraulic and electrical modes.

4. High reliability and long service life. The effective action times of electrical components are about one million times, while the life of the general solenoid valve is more than 30 million times, some valves of good quality are more than 200 million times.

5. Use the compressibility of air to store energy and realize centralized air supply. Energy can be released in short time to obtain high speed response in intermittent motion. Buffers can be implemented. Strong adaptability to shock load and over load. Under certain conditions, the pneumatic device can be self-maintaining ability.

6, all pneumatic control with fire, explosion, moisture-proof ability. Compared with the hydraulic mode, the pneumatic mode can be used in high temperature occasions.

7, compressed air can be centralized supply, long-distance transmission.

Detailed Date in the Excel

Drawings of 4V230-08

Product features:

1. Pilot mode: external and internal optional;

2, sliding column structure, good sealing, responsive;

3, three position solenoid valve has three central functions to choose from;

4, double head two position solenoid valve has memory function;

5. The inner hole is processed with special technology, with small friction resistance, low starting pressure and long service life;

6. No need for lubrication;

7. The valve set can be integrated with the base to save installation space;

8. Manual device is attached to facilitate installation and debugging;

9. A variety of standard voltage grades are available.

Principle of 4V230-08

There is a closed cavity in the pneumatic solenoid valve, in different positions open through holes, each hole of the pneumatic solenoid valve is to a different trachea, the middle of the cavity is the valve, two sides are two electromagnet, which side of the magnet coil energized valve body will be attracted to which side;

Pneumatic solenoid valve to control the movement of the valve body to blocked or leakage of different exhaust hole, and the air inlet is always open, high pressure gas will enter different exhaust pipe, and then through the pneumatic pressure to push the cylinder piston of solenoid valve, pneumatic solenoid valve control through the electromagnet so current electromagnetic valve to control the whole mechanical movement.
