5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine

5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine

    • 5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine
    • 5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine
    • 5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine
    • 5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine
  • 5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine

    Product Details:

    Place of Origin: CHINA NINGBO
    Brand Name: Brando
    Certification: CE
    Model Number: 4V320-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 2 sets
    Price: negotiation
    Packaging Details: Inner Boxes,Cartons,Pallets
    Delivery Time: 4-10 days
    Payment Terms: L/C, T/T, Western Union,Paypal
    Supply Ability: 110000 sets per month
    Contact Now
    Detailed Product Description
    Port Size: 1/4'' Or 3/8'' Material: Alloy,Aluminium
    Power: Pneumatic Structure: Pilot
    Pressure: Medium Pressure Media: Air
    Application: Automation Equipment Type: Normally Closed
    Motion Pattern: Inner Piloted Type Voltage: DC12V DC24V AC24V AC110V AC220V AC380V

    5ways 2 positions 4V320-10 Pneumatic Electromagnetic Valve For Automation Machine



    4V320-10 pneumatic solenoid valve is an electtomagnetic valve of the cylinder air path of the controller, which is used for switching and controlling the opening and closing of the gas path, and controls the compressed air to act on the cylinder to cause the cylinder to generate motion and action. Cylinders are pneumatic mechanical components used to effect mechanical motion or motion and are driven by compressed air. With the cylinder and solenoid valve, the controller of the cylinder is also needed. Usually, the tpc8-8td timing program controller is used as the controller of the cylinder. The functions required for the table setting are adopted, and the automatic control of the cylinder device can be conveniently realized without programming.



    Technical data of 4V320-10 pneumatic solenoid valve:

    Models 4V310-10 4V320-10 4V330C-10 4V330E-10 4V330P-10
    Position number Two positions five ways Three positions five ways
    Operating medium 40 Mircon litered Clean Air
    Action type Internally pilot operated
    Wiring Form Lead wire or Connector type
    Packing dimension 13.52x2.7x4cm 19.04x2.7x4cm 20.94x2.7x4 cm
    Highest action frequency 5 cycles per second



    Product parts profile of 4V pneumatic electromagnetic valves:

    5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine



    Detail enlargement of 4V Automation control valve (Coil,Pipe Hole& Pilot):

    5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine



    Application field of 4V pneumatic solenoid valves in automation:

    5 Way 2 Position Pneumatic Electromagnetic Valve 4V320-10 For Automation Machine



    CNC machine with 4V series pneumatic solenoid valves structure:
    1. Host engine, which is the main body of CNC machine tools, including machine parts, column, spindle, feed mechanism and other mechanical parts. It is a mechanical part that performs various cutting operations.


    2. Driving unit: it is the driving unit of CNC machine tool actuator, including spindle driving unit, feed unit, spindle motor and feed motor. He drives the spindle and feed through an electrical or electro-hydraulic servo system controlled by a CNC unit. When multiple feeders are connected, positioning, straight line, plane curve and space curve can be processed.


    3. Numerical control device is the core of numerical control machine tool, including hardware (printed circuit board, CRT display, key box, tape reader, etc.) and corresponding software, which is used to input the program of digital parts and complete the storage of input information. Data conversion, interpolation operation, various control functions.


    4. Auxiliary equipment: some necessary parts of CNC machine tools, such as cooling, chip removal, lubrication, lighting, monitoring, etc., to ensure the operation of CNC machine tools. It includes hydraulic and pneumatic devices, chip removal devices, switchboards, nc turntables and nc dividing heads, and tools and monitoring and inspection devices. Programming and other auxiliary equipment: can be used for programming, storage machine parts, etc.
