3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector

3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector

  • 3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector
3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector
Product Details:
Place of Origin: China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: G353A041
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4 to 7 days
Payment Terms: T/T, PayPal, Western Union, L/C
Supply Ability: 10000pcs per month
Contact Now
Detailed Product Description
Pilot Port Size: 1/8'' Inlet & Outlet Port Size: 3/4''
Valve Structure: Right Angle, Threaded Port Valve Operation: Remote Pilot, Diaphragm Pilot Operated
Diaphragm Material: TPE, NBR, FKM Working Pressure Range: 0.35 To 0.85 MPa
High Light:

3/4'' Pulse Jet Valve

,

Remote Pulse Jet Valve

,

Remote Pulse Valves

3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector



Diaphragm pulse valves are the most important components of a baghouse pulse jet cleaning system. On a pulse jet baghouse pulse valves (also called diaphragm valves) control the release of air pulses during the cleaning cycle. When the baghouse control board or timer board initiates a cleaning cycle it sends an electrical signal to the solenoids, when then activate the pulse valve. Inside the pulse valve, a rubber diaphragm opens and closes to release the compressed air stored in the air header tank. The air then passes through the valve into the blow pipes above the filters and then is directed down into the filters to clean them.



Technical Data of Remote Pilot Threaded Pulse Jet Valves:

Port
Size
Remote Pilot Connection
Office Size
Operating Pressure Differential (Bar)
Model Number
Diaphragm Material
Inch
φB
(mm)
Min.
Max.
Aluminium



TPE, NBR, or Viton
3/4''
1/8''
24
0.35
8.5
G353A041
1''
1/8''
27
0.35
8.5
G353A042
1 1/2''
1/4''
52
0.35
8.5
G353A045


Main Dimension of Remote Pilot Threaded Pulse Jet Valves:

3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 0

Model No
A
B
C
D
E
F
G
G353A041
-
1/8''
51
89
75
41
65
G353A042
-
1/8''
51
89
75
41
64
G353A045
30
1/4''
71
130
136
71
98



Video of G353A041 Pulse Jet Valve:



More ASCO Type Pulse Valves for you to choose:

3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 1 3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 2 3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 3 3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 4
Threaded Type Remote Pilot Type Straight Through Type Submerged Type
3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 5 3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 6 3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 7 3/4'' G353A041 ASCO Type Remote Pilot Pulse Jet Valve For Dust Collector 8
Diaphragm Solenoid Coil Solenoid Armature Pulse Controller
