Place of Origin: | China |
Brand Name: | Brando |
Certification: | ISO, CE |
Model Number: | RCA76T |
Minimum Order Quantity: | 1pc |
---|---|
Price: | Negotiation |
Packaging Details: | Inner Box, Carton, Pallet |
Delivery Time: | 4 to 7 days |
Payment Terms: | T/T, PayPal, Western Union, L/C |
Supply Ability: | 100000 pcs per month |
Port Size: | 3'' | Pilot Size: | 1/8'', 1/4'' |
---|---|---|---|
Valve Series: | T | Valve Structure: | Right Angle, Threaded Port |
Diaphragm Material: | NBR, FKM | Working Pressure Range: | 0.35 To 0.85 MPa |
Highlight: | Goyen Pulse Valve RCA76T,Remote Pulse Valves,Air Operated Pulse Valve |
3'' RCA76T Goyen Type Air Control Remote Pulse Valve For Dust Removal
Pulse valves (also called diaphragm valves) are the “switch” for compressed air in the dust clean blowing system of the pulse bag filter. It is used to control the release of air pulses in the cleaning cycle. When the dust collector control board starts the cleaning cycle, it sends an electrical signal to the solenoid valve, and then activates the pulse valve. Inside the pulse valve, the rubber diaphragm opens and closes to release the compressed air stored in the air header. At this time, the air enters the blowing pipe above the filter through the valve, and then enters the filter down to clean the filter bag.
Technical Data of T Series Pulse Jet Valves:
Model Number
|
RCA15T
|
RCA20T
|
RCA25T
|
RCA35T
|
RC45T
|
RCA50T
|
RCA62T
|
RCA76T
|
Office Size
(mm)
|
15
|
20
|
25
|
35
|
45
|
50
|
62
|
76
|
Port Size
(Inch)
|
1/2''
|
3/4''
|
1''
|
1 1/2''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
Diaphragm Number
|
1
|
2
|
||||||
Pilot Size
|
1/8'', 1/4''
|
|||||||
Working pressure
|
0.35 to 0.85 MPa
|
|||||||
Diaphragm Material
|
NBR, FKM, EPDM
|
|||||||
Body Material
|
Aluminum Alloy
|
|||||||
Valve Structure
|
Right Angle (Outlet is at 90° to Inlet), Threaded Port
|
Ordering Code of T Series Pulse Jet Valve:
Main Dimension of RCA76T Pulse Jet Valve:
More Goyen Type Pulse Valves for you to choose:
![]() |
![]() |
![]() |
![]() |
T Series | DD Series | FS Series | MM Series |
![]() |
![]() |
![]() |
![]() |
RCA Series | Solenoid Coil | Solenoid Armature | Diaphragm |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
