PCF Female Straight Push-In Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2''

PCF Female Straight Push-In Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2''

PCF Female Straight Push-In Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2''
video
PCF Female Straight Push-In Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2''
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: PCF
Payment & Shipping Terms:
Minimum Order Quantity: 5 pcs
Price: Negotiation
Packaging Details: PVC bag, then inner box, then carton, then pallet
Delivery Time: 1 week after payment
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 10000000pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Hose Fittings Type: Female Straight
Tube OD (Inch): 1/8", 1/4", 3/8", 1/2" Tube OD (Mertric): 4mm, 6mm, 8mm, 10mm, 12mm
Color: Blue, Black, Gray Material: Plastic
Working Pressure Range: 0 To 0.8MPa Working Temperature Range: 0 To +60℃
High Light:

Push-In Pneumatic Hose Fittings

,

1/4'' Pneumatic Hose Fittings

,

Quick Pneumatic Fitting

PCF Female Straight Push-In Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2''


Most popular straight push-in fittings with male or female threads. Fittings have hexagonal body allowing tightening with wrench, additionally our fittings can be screwed with tool, which is especially convenient where there is limited access to installation place. In this category you can find push-in fittings with threads in following sizes: M5, 1/8'', 1/4'', 3/8'' and 1/2'' for hoses with diameter from 4 mm to 16 mm.


Technical data of Pneumatic Hose Fittings:

Material
Plastic / Brass
Threaded Connection
BSP
BSPP
Metric Thread
NPT
Working Pressure
0 to 0.8MPa
Connecting Tube
PA
PU
Connecting Diameter Tube
3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm (Outer Diameter)
Medium
Compressed Air
Working Temperature
~60℃



Specifications of PCF Female Straight Pneumatic Hose Fittings:

                                             PCF Female Straight Push-In Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2'' 0

Model No
M
φD
D1
L1
L
S
PCF4
M5x0.8
4
11
6
22
12
M6X1
6
22
12
G1/8''
7
23
13
G1/4''
8
24
16
G3/8''
9
25
19
G1/2''
10
26
24
PCF6
M5X0.8
6
13
6
23
13
M6X1
6
23
13
G1/8''
7
24
13
G1/4''
8
25
16
G3/8''
9
26
19
G1/2''
10
27
24
PCF8
G1/8''
8
15
7
26
15
G1/4''
8
27
16
G3/8''
9
28
19
G1/2''
10
29
24
PCF10
G1/8''
10
17
7
28
17
G1/4''
8
29
17
G3/8''
9
30
19
G1/2''
10
31
24
PCF12
G1/8''
12
21
7
30
21
G1/4''
8
31
21
G3/8''
9
32
21
G1/2''
10
33
24


List of All Push To Connect Pneumatic Hose Fittings:

PL Male 90 Degree Elbow Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2'' 1



Choosing the Right Fittings for Your Pneumatic System:



Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
