Festo Type LR-1/2-D-MIDI Pressure Regulator 159581 G1/2''

Festo Type LR-1/2-D-MIDI Pressure Regulator 159581 G1/2''

The Festo type LR-1/2-D-MIDI Pressure Regulator (159581) is an industrial pneumatic pressure regulator designed to maintain a consistent downstream air pressure in compressed air systems. Part of Festo's D-series MIDI range, this regulator helps provide stable pressure control for pneumatic machinery, automation equipment and industrial manufacturing applications.

Featuring G1/2 threaded pneumatic connections, an adjustable pressure range of 0.5 to 12 bar and an integrated pressure gauge, the Festo LR-1/2-D-MIDI offers practical pressure control for industrial pneumatic installations.

Key Features

Model: LR-1/2-D-MIDI
Part Number: 159581
Product Type: Pneumatic pressure regulator
Series: Festo D Series, MIDI size
Port Connection: G1/2 inch
Pressure Regulation Range: 0.5–12 bar
Maximum Operating Pressure: 16 bar
Nominal Flow Rate: 3,500 L/min
Pressure Gauge: Included
Regulator Design: Directly actuated diaphragm regulator
Operating Temperature: -10°C to +60°C
