AIRTAC Type 4V320-10 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 3/8 Inch

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	4V320-10

Payment & Shipping Terms:

Minimum Order Quantity:	300pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=3/8'', Exhaust=1/4''	Pressure Range:	0.15 To 0.8 MPa
Body Material:	Aluminum Alloy	Valve Type:	5/2 Way, Double Solenoid
Max Pressure Resistance:	1.5MPa (215PSI)	Fluid:	Air
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Highlight:	AIRTAC 4V320-10 , AirTAC 4V320-10 solenoid valve , 4V320-10 pneumatic valve

AIRTAC Type 4V320-10 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 3/8 Inch

The AIRTAC type 4V320-10 is a 5-port, 2-position (5/2 way) double solenoid pneumatic valve from the AirTAC type 4V300 series. It is designed for directional control of double-acting pneumatic cylinders and industrial automation equipment requiring reliable and stable air switching. The valve features 3/8 inch inlet and outlet ports, a spool-type structure, and a double solenoid control system with memory function.

The double solenoid design allows the valve spool to remain in its last position after the electrical signal is removed, making the 4V320-10 suitable for automation systems where stable cylinder positioning and efficient electrical control are required.

Data of 4V300 Series Pneumatic Solenoid Valves:

Model	4V310-08 4V320-08	4V330C-08 4V330E-08 4V330P-08	4V310-10 4V320-10	4V330C-10 4V330E-10 4V330P-10
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=Exhaust=1/4''		In=Out=3/8'' Exhaust=1/4''
Orifice Size	25.00 mm2 (Cv=1.40)	18.00 mm2 (Cv=1.00)	30.00 mm2 (Cv=1.68)	18.00 mm2 (Cv=1.00)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa(21~114psi)
Proof Pressure	1.5MPa(215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	4 cycle/sec	4 cycle/sec	4 cycle/sec	4 cycle/sec

Dimension of 4V320-10 Pneumatic Solenoid Valve:

AIRTAC Type 4V320-10 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 3/8 Inch

Product video of 4V320-10 Pneumatic Solenoid Valve:
