AIRTAC Type 4V320-08 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 1/4 Inch

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	4V320-08

Payment & Shipping Terms:

Minimum Order Quantity:	300pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=Exhaust=1/4''	Pressure Range:	0.15 To 0.8 MPa
Body Material:	Aluminum Alloy	Valve Type:	5 Way 2 Position
Max Pressure Resistance:	1.2MPa	Fluid:	Air
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Highlight:	AIRTAC 4V320-08 , AirTAC 4V320-08 solenoid valve , 4V320-08 pneumatic valve

AIRTAC Type 4V320-08 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 1/4 Inch

The AIRTAC type 4V320-08 is a 5-port, 2-position (5/2 way) double solenoid pneumatic valve from the AirTAC type 4V300 series. It is designed for directional control of double-acting pneumatic cylinders and industrial automation equipment. With a 1/4 inch port size, spool-type construction, and double electrical control design, the valve provides stable and reliable air switching performance.

The double solenoid configuration provides memory function, allowing the valve spool to remain in its last switched position after the electrical signal is removed. This makes the 4V320-08 suitable for applications requiring stable cylinder control and reduced continuous power consumption.

Technical Data of 4V300 Series Solenoid Valve:

Model	4V310-08	4V320-08	4V330C-08 4V330E-08 4V330P-08	4V310-10	4V320-10	4V330C-10 4V330E-10 4V330P-10
Fluid	Air (to be filtered by 40 μm filter element)
Acting	internal pilot or external pilot
Port Size	in=out=exhaust=1/4''			in=out=3/8'', exhaust=1/4''
Orifice Size	4V310-10, 4V320-10: 28.0mm² (Cv=1.65) 4V330C-10: 21.3mm² (Cv=1.25)
Vlave Type	5 way 2 position		5 way 3 postion	5 way 2 position		5 way 3 position
Operating Pressure	0.15 to 0.8 MPa (21 to 114 psi)
Proof Pressure	1.2MPa (175psi)
Temperature	-20 to +70℃
Body Material	Aluminum Alloy
Max Frequency	5 cycle/sec		3 cycle/sec	5 cycle/sec		3 cycle/sec
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
