AIRTAC Type 4V310-08 Solenoid Valve 5/2 Way Pneumatic Valve 1/4 Inch Single Solenoid

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	4V310-08

Payment & Shipping Terms:

Minimum Order Quantity:	300pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=Exhaust=1/4''	Pressure Range:	0.15 To 0.8 MPa
Body Material:	Aluminum Alloy	Valve Type:	5 Way 2 Position
Max Pressure Resistance:	1.2MPa	Fluid:	Air
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Highlight:	AIRTAC 4V310-08 , AirTAC 4V310-08 solenoid valve , 4V310-08 pneumatic valve

AIRTAC Type 4V310-08 Solenoid Valve 5/2 Way Pneumatic Valve 1/4 Inch Single Solenoid

The AIRTAC type 4V310-08 is a 5-port, 2-position (5/2 way) single solenoid pneumatic valve from the AirTAC type 4V300 series. It is designed for controlling the direction of compressed air in double-acting pneumatic cylinders and automation equipment. With a 1/4 inch port size, durable aluminum alloy body, and reliable spool structure, the valve provides stable performance for industrial pneumatic applications.

The single solenoid spring return design allows the valve to switch when energized and return to its original position after power is removed, making it suitable for automated machinery requiring dependable pneumatic control.

Technical Data of 4V300 Series Solenoid Valve:

Model	4V310-08	4V320-08	4V330C-08 4V330E-08 4V330P-08	4V310-10	4V320-10	4V330C-10 4V330E-10 4V330P-10
Fluid	Air (to be filtered by 40 μm filter element)
Acting	internal pilot or external pilot
Port Size	in=out=exhaust=1/4''			in=out=3/8'', exhaust=1/4''
Orifice Size	4V310-10, 4V320-10: 28.0mm² (Cv=1.65) 4V330C-10: 21.3mm² (Cv=1.25)
Vlave Type	5 way 2 position		5 way 3 postion	5 way 2 position		5 way 3 position
Operating Pressure	0.15 to 0.8 MPa (21 to 114 psi)
Proof Pressure	1.2MPa (175psi)
Temperature	-20 to +70℃
Body Material	Aluminum Alloy
Max Frequency	5 cycle/sec		3 cycle/sec	5 cycle/sec		3 cycle/sec
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
