Name: AIRTAC Type 4V130C-06 Solenoid Valve 5/3 Way Closed Center Pneumatic Valve 1/8 Inch
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 4V130C-06
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Solenoid Valve

AIRTAC Type 4V130C-06 Solenoid Valve 5/3 Way Closed Center Pneumatic Valve 1/8 Inch

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	4V130C-06

Payment & Shipping Terms:

Minimum Order Quantity:	300pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=1/8''	Pressure Range:	0.15 To 0.8 MPa (21 To 114 Psi)
Body Material:	Aluminum Alloy	Valve Type:	5 Port 2 Position
Max Pressure Resistance:	1.2MPa (175psi)	Fluid:	Air (to Be Filtered By 40 μm Filter Element)
Voltages:	220V AC, 110V AC, 24V AC, 24V DC, 12V DC
Highlight:	AIRTAC 4V130C-06 , AirTAC 4V130C-06 solenoid valve , 4V130C-06 pneumatic valve

AIRTAC Type 4V130C-06 Solenoid Valve 5/3 Way Closed Center Pneumatic Valve 1/8 Inch

The AIRTAC type 4V130C-06 is a 5-port, 3-position (5/3 way) double solenoid pneumatic valve from the AirTAC type 4V100 series. It features a closed center configuration, allowing the actuator to stop and hold its position when both solenoids are de-energized. This valve is widely used for precise directional control of double-acting pneumatic cylinders and automation equipment.

The compact 1/8 inch port design, aluminum alloy body, and spool-type construction provide reliable operation in industrial pneumatic applications including machinery automation, assembly equipment, and motion control systems.

Data of 4V100 Series Pneumatic Solenoid Valves:

Model	4V110-06 4V120-06	4V130C-06 4V130E-06 4V130P-06	4V110-08 4V120-08	4V130C-08 4V130E-08 4V130P-08
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=1/8''		In=Out=1/4''
Orifice Size	5.5 mm2 (Cv=0.31)	5.0 mm2 (Cv=0.28)	12.00 mm2 (Cv=0.67)	9.00 mm2 (Cv=0.50)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof Pressure	1.5MPa (215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	5 cycle/sec	3 cycle/sec	5 cycle/sec	3 cycle/sec

Main Dimension of 4V130C-06 Solenoid Valve:

4V130C-06 Airtac Type Pneumatic Double Solenoid Valve 5/3 Way 24V 220V 0

Production Video of Pneumatic Solenoid Valves:

More Pneumatic Products for you to choose:

4V110-06 Airtac Type Pneumatic Solenoid Valve 4V110-06-DC24V 24VDC 1 pneumatic fast fittings

Solenoid Operator Manifold Silencer Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
