Name: AIRTAC Type 4V120-06 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 1/8 Inch
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 4V120-06
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Solenoid Valve

AIRTAC Type 4V120-06 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 1/8 Inch

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	4V120-06

Payment & Shipping Terms:

Minimum Order Quantity:	300pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=1/8''	Pressure Range:	0.15 To 0.8 MPa
Body Material:	Aluminum Alloy	Valve Type:	5 Port 2 Position
Max Pressure Resistance:	1.2MPa	Fluid:	Air (to Be Filtered By 40 μm Filter Element)
Voltages:	220V AC, 110V AC, 24V AC, 24V DC, 12V DC
Highlight:	AirTAC 4V120-06 solenoid valve , 4V120-06 pneumatic valve , AIRTAC 4V120-06

AIRTAC Type 4V120-06 Solenoid Valve 5/2 Way Double Solenoid Pneumatic Valve 1/8 Inch

The AIRTAC type 4V120-06 is a compact 5-port, 2-position (5/2 way) double solenoid pneumatic valve designed for directional control of double-acting cylinders and industrial automation equipment. It is part of the AirTAC type 4V100 series and features a 1/8" port size, spool valve structure, and memory function for stable pneumatic control.

The double solenoid design allows the valve spool to remain in its last position after the electrical signal is removed, making it suitable for applications requiring reliable switching and position memory.

Data of 4V100 Series Pneumatic Solenoid Valves:

Model	4V110-06 4V120-06	4V130C-06 4V130E-06 4V130P-06	4V110-08 4V120-08	4V130C-08 4V130E-08 4V130P-08
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=1/8''		In=Out=1/4''
Orifice Size	5.5 mm2 (Cv=0.31)	5.0 mm2 (Cv=0.28)	12.00 mm2 (Cv=0.67)	9.00 mm2 (Cv=0.50)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof Pressure	1.5MPa (215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	5 cycle/sec	3 cycle/sec	5 cycle/sec	3 cycle/sec

Main Dimension of 4V120-06 Solenoid Valve:

4V120-06 Airtac Type 5/2 Pneumatic Double Solenoid Valve 24VDC 220VAC 0

Production Video of Pneumatic Solenoid Valves:

More Pneumatic Products for you to choose:

4V110-06 Airtac Type Pneumatic Solenoid Valve 4V110-06-DC24V 24VDC 1 pneumatic fast fittings

Solenoid Operator Manifold Silencer Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
