ADRHE-6 7/8" ODF Discharge Bypass Valve Sporlan Type ADRHE-6-0/80 ADRHE-6-0/30

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	ADRHE-6

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Hot Gas Bypass Valve	External Equalizer Connection:	1/4'' (ODF)
Connection Size:	5/8'', 7/8'', 1-1/8'' (ODF)	Equalization:	Externally Equalized
Refrigerant:	R134a, R401A, R22, R402A, R404A, R407C, R507	Adjustment Range:	0/30, 0/80 (psig)
Voltage:	24VDC, 24VAC, 110VAC, 220VAC
Highlight:	Sporlan ADRHE-6-0/30 , Sporlan ADRHE-6-0/80 , Discharge Bypass Valve Sporlan

ADRHE-6 7/8" ODF Discharge Bypass Valve Sporlan Type ADRHE-6-0/80 ADRHE-6-0/30

The primary function of ADR discharge hot gas bypass valves, referred to as DBV valves, is to limit the minimum evaporating pressure during periods of low load either to prevent coil icing or avoid operating the compressor at a lower suction pressure than it was designed to operate. Each valve is factory tested to ensure positive leak-free performance.

Technical Data:

Model No	Valve Type	Equalized Size	Inlet & Outlet Size	Adjustment Range (psig)	Standard Setting (psig)
ADRSE-2	Externally Equalized	1/4'' ODF	3/8'' ODF	0 to 30 0 to 80	20 60
			1/2'' ODF
			5/8'' ODF
ADRPE-3			1/2'' ODF
			5/8'' ODF
ADRHE-6			5/8'' ODF
			7/8'' ODF
			1-1/8'' ODF

Cooling Capacity (KW):

R22

Min Evaporator Temperature	Adjustment Range
	ADRIE-1-1/4			ADRSE-2		ADRPE-3		ADRHE-6
	0/55psig	0/75psig	0/100psig	0/30psig	0/80psig	0/30psig	0/80psig	0/30psig	0/80psig
	0/3.79bar	0/5.17bar	0/6.9bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar
5℃	-	2.04	1.86	-	12.3	-	21.1	-	32.2
-5℃	1.55	2.25	1.9	-	12.5	-	22	-	34.8
-15℃	2.22	2.11	1.72	13.7	12.9	26	23.2	48.9	38.3
-25℃	2.08	1.76	1.55	13.2	12.8	26.2	23.4	49.6	38.7

R134a

Min Evaporator Temperature	Adjustment Range
	ADRIE-1-1/4			ADRSE-2		ADRPE-3		ADRHE-6
	0/55psig	0/75psig	0/100psig	0/30psig	0/80psig	0/30psig	0/80psig	0/30psig	0/80psig
	0/3.79bar	0/5.17bar	0/6.9bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar
5℃	1.41	1.51	1.19	-	9.4	-	17.4	-	32.9
-5℃	1.44	1.37	1.12	9.15	8.59	17.4	15.5	32.9	25.5
-15℃	1.34	1.09	0.98	8.66	-	17.2	-	33.1	-

R404A

Min Evaporator Temperature	Adjustment Range
	ADRIE-1-1/4			ADRSE-2		ADRPE-3		ADRHE-6
	0/55psig	0/75psig	0/100psig	0/30psig	0/80psig	0/30psig	0/80psig	0/30psig	0/80psig
	0/3.79bar	0/5.17bar	0/6.9bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar
5℃	-	-	1.94	-	-	-	-	-	-
-5℃	-	2.36	2.11	-	13.7	-	23.6	-	36.6
-15℃	2.35	2.5	1.97	-	14.1	-	25.2	-	41.2
-25℃	2.39	2.15	1.79	14.7	14.1	28.4	25.6	53.8	42.6

R407C

Min Evaporator Temperature	Adjustment Range
	ADRIE-1-1/4			ADRSE-2		ADRPE-3		ADRHE-6
	0/55psig	0/75psig	0/100psig	0/30psig	0/80psig	0/30psig	0/80psig	0/30psig	0/80psig
	0/3.79bar	0/5.17bar	0/6.9bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar	0/2.07bar	0/5.52bar
5℃	-	2.74	2.29	-	14.9	-	26.4	-	42.6
-5℃	2.15	2.74	2.22	-	14.9	-	26.4	-	42.6
-15℃	2.6	2.39	1.97	15.9	15.2	30.4	27.5	57.3	45.7
-25℃	2.39	1.97	1.76	15.2	14.9	30.4	27.1	58	45.4

Main Dimension:

Model No	Inlet & Outlet	A	B	C	D	E	F
ADRSE-2	3/8'' ODF	164	64	50	37	37	61
	1/2'' ODF				35	35
	5/8'' ODF				38	38
ADRPE-3	1/2'' ODF	178	72	53	43	41	61
	5/8'' ODF				55	55
ADRHE-6	5/8'' ODF	180	73	48	117	117	70
	7/8'' ODF
	1-1/8'' ODF
