Name: K0580 M1141B K0581 M1168 Solenoid Kit for GOYEN Type RCA5D2 RCA5D1
Brand: Ningbo Brando Hardware Co., Ltd
SKU: BAPC213556562-1
Price: 49.10 USD
Availability: InStock

Home Products Solenoid Valve Armature

K0580 M1141B K0581 M1168 Solenoid Kit for GOYEN Type RCA5D2 RCA5D1

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	None
Model Number:	BAPC213556562-1

Payment & Shipping Terms:

Minimum Order Quantity:	500sets
Price:	Negotiation
Packaging Details:	Plastic bag, Box, Carton, Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,PayPal,Western Union
Supply Ability:	100000sets per month

Contact Now

Detailed Product Description

Product Name:

Solenoid Armature

Ref No:

K0580 (M1141B). K0581 (M1168)

Seal Material:

NBR (Standard), FKM (Optional)

Fitted Solenoid Valve Model No:

RCA5D2, RCA5D1, RCA5D0, RCA5-6V, RCA5-5V

Highlight:

Solenoid Kit for GOYEN RCA5D2

Solenoid Valve Armature Kit

GOYEN RCA5D1 Solenoid Kit

K0580 M1141B K0581 M1168 Solenoid Kit for GOYEN Type RCA5D2 RCA5D1

This solenoid armature kit is popularly used in GOYEN RCA5D2, RCA5D1, RCA5D0, RCA5-6V, RCA5-5V solenoid valves and pilot enclosures. The reference number is K0580 (M1141B) or K0581 (M1168). The seal material can be NBR (Standard) or FKM (Optional). 1 set includes 1pc tube, 1pc core, 1pc spring, 1pc clip, 3pcs crews, 1pc small o-ring, 1pc big o-ring, 1pc gasket. If you have any demands, pls contact us!

Technical Data:

BRANDO Model	BAPC213556562-1
Ref No	K0580 (M1141B) K0581 (M1168)
Plunger Tube Material	Stainless Steel
Seal Material	NBR (Standard) FKM (Optional)

Fitted Coil:

BRANDO Model	BB14038895
Ref No	RCA5D2, BC
Voltage	220VAC, 110VAC, 24VAC, 24VDC
Power	19W
Other voltage and power can be customized
Connector	Screw Terminal

Our Production:

Related Products:


RCA5D Solenoid Coil	RCA5D Solenoid Valve	Pulse Valve	Pilot Valve Enclosure	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
