13mm OD M17 Thread Solenoid Valve Armature For LPG CNG Repair Kit

13mm OD M17 Thread Solenoid Valve Armature For LPG CNG Repair Kit

  • 13mm OD M17 Thread Solenoid Valve Armature For LPG CNG Repair Kit
  • 13mm OD M17 Thread Solenoid Valve Armature For LPG CNG Repair Kit
13mm OD M17 Thread Solenoid Valve Armature For LPG CNG Repair Kit
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: None
Model Number: BAPC213036043
Payment & Shipping Terms:
Minimum Order Quantity: 1000
Price: Negotiation
Packaging Details: inner boxes,cartons,pallets
Delivery Time: Negotiation
Payment Terms: T/T,PayPal,Western Union
Supply Ability: 300000sets per month
Contact Now
Detailed Product Description
Product Name: Solenoid Valve Armature Core Tube Material: Brass
Seal Material: FKM Function: 2 Way Normally Closed
Plunger Tube Outer Diameter: 13mm Mounting Type: M17 Thread
Application: LPG/CNG
Highlight:

M17 Thread Solenoid Valve Armature Kit

,

LPG CNG Armature Plunger Tube

,

M17 Thread LPG CNG Armature

13mm OD M17 Thread Solenoid Valve Armature For LPG CNG Repair Kit


This solenoid armature is popularly used in LPG reducers, CNG reducers. The color of the solenoid coil can be customized according to your requirements, such as black, red, blue, etc. The CNG fuel system releases high-pressure gas from the fuel tank and transfers it through the fuel lines. The pressure regulator reduces the pressure, which is compatible with the engine fuel injection system. Then, CNG transfers to the combustion or manifold chamber, mixing with air. The spark plug ignites the compressed gas and starts the engine.


Technical Data:

Model Number
BAPC213036043
Guide Tube Outer Diameter
13.0mm
Installation Height for Coil Assembling
33.5mm
Guide Tube Material
Brass
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
M17 Thread
Voltage
All range of AC and DC available
Position and Way
2/2 Way
Non-working Status
Normally Closed
Application Examples
LPG, CNG


Main Dimension:

13mm OD M17 Thread Solenoid Valve Armature For LPG CNG Repair Kit 0



Our Production:

LPG CNG Reducer Regulator Solenoid Armature Plunger Tube And Core 1


More LPG CNG Solenoid Armatures:

LPG CNG Solenoid Armature LPG CNG Solenoid Armature LPG CNG Solenoid Armature LPG CNG Injector Rail Solenoid Plunger


More LPG CNG Solenoid Coils:

LPG CNG Solenoid Coil Solenoid Coil 12VDC 17W LPG CNG Solenoid Coil LPG CNG Solenoid Valve Coil



Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
