Danfoss Type EVRA 32 042H1126 Electromagnetic Valve EN-JS1025

Danfoss Type EVRA 32 042H1126 Electromagnetic Valve EN-JS1025

EVRA 32 ( EN-JS1025 ) ammonia solenoid valve; 042H1126, 042H1127, 042H1131, 042H1140, 042H1141, 042H1190 ordering code; flange connection type. EVRA 32 is a servo operated piston solenoid valve.The valves are closed with currentless coil.The servo piston with main valve plate closes against the valve seat by means of the differential pressure between inlet and outlet side of the valve, the force of the compression spring and possibly the piston weight. When current to the coil is switched on, the pilot orifice opens. This relieves the pressure on the piston spring side of the valve. The differential pressure will then open the valve. The minimum differential pressure needed for full opening of the valves is 0.2 bar.

Main Dimension of EVRA 32 Ammonia Solenoid Valve:

Video of EVRA 32 Ammonia Solenoid Valve:

Ordering Code of Ammonia Solenoid Valves:

Separate valve bodies with manual operation

Separate valve bodies without manual operation:

Separate valve bodies with butt weld connections:

More Refrigeration Solenoid Valves for you to choose:

Danfoss Type Solenoid Valve	Ammonia Solenoid Valve	Castel Type Solenoid Valve
Expansion Valve	Solenoid Valve Coil	Solenoid Valve Armature
