Name: Danfoss Type Solenoid Valve EVR 40 1 5/8 in 042H1109 042H1110
Brand: Ningbo Brando Hardware Co., Ltd
SKU: BRV40-158S
Price: 65.00 USD
Availability: InStock

Home Products Refrigeration Solenoid Valve

Danfoss Type Solenoid Valve EVR 40 1 5/8 in 042H1109 042H1110

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	BRV40-158S

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Refrigeration Solenoid Valve	Ordering Code:	042H1109, 042H1110
Port Size:	1 5/8'' (42mm)	Connection Type:	Solder (ODF)
Function:	2 Way Normally Closed	Voltage:	24VDC, 24VAC, 110VAC, 220VAC
Seal Material:	PTFE	Body Material:	Brass
Application:	Chiller, Freezer, Air Conditioning, Cooler, Etc
Highlight:	Danfoss 042H1110 solenoid valve 1 5/8 in , Danfoss Solenoid Valve Evr40 042H1109 , Solenoid valve EVR 40 1 5/8''

Danfoss Type Solenoid Valve EVR 40 1 5/8 in 042H1109 042H1110

EVR 40 (EN-JS1025) refrigeration solenoid valve; 042H1110, 042H1112, 042H1114, 032L1110, 032L1112, 032L1114 ordering code; 1 5/8'', 2 1/8'' port size; solder connection type. Refrigeration solenoid valves offer advanced control of capacity, hot gas by-pass and liquid injection in your air conditioning system. Our refrigerartion solenoid valves are suited for use in the widest range of applications in terms of function, capacity and design. With our solenoid valve portfolio you get maximum flexibility combined with optimum performance and efficiency.

Main Dimension of EVR 40 Solenoid Valve For Refrigeration:

Danfoss Type Solenoid Valve EVR 40 1 5/8 in 042H1109 042H1110 0

Type	Connection		H1	H2	H4	L	L2	L5
	inch	mm
EVR 40	1 5/8''	42	47	111	53	281	29	75
	2 1/8''	54	47	111	53	281	34	75

Ordering Code of Danfoss Type Solenoid Valve:

EVR solder connection, Normally Closed (NC) - separate valve bodies

Type	Connection Size (Inch)	Connection Size (mm)	Manual Operation	Code No
EVR 2	1/4	-	NO	032F1201
	1/4	-		032F7100
	-	6		032F1202
EVR 3	1/4	-	NO	032F1206
	3/8	-		032F1204
	-	6		032F1207
	-	10		032F1208
EVR 6	1/2	-	NO	032F1209
	3/8	-		032F1212
	-	10		032F1213
	-	12		032F1236
EVR 10	1/2	-	NO	032F1217
	-	12		032F1218
	5/8	16		032F1214
EVR 15	7/8	22	NO	032F1225
	-	16	YES	032F1227
	5/8	16	NO	032F1228
EVR 20	7/8	22	NO	032F1240
	7/8	-	YES	032F1254
	1 1/8	-	NO	032F1244
	-	28	NO	032F1245
	7/8	22	NO	032F1264
	7/8	-	YES	032F1274
EVR 22	1 3/8	35	NO	032F3267
EVR 25	1 1/8	-	YES	032F2200
	1 1/8	-	NO	032F2201
	-	28	YES	032F2205
	-	28	NO	032F2206
	1 3/8	-	YES	032F2207
	1 3/8	-	NO	032F2208
EVR 32	1 5/8	-	YES	042H1103
	1 5/8	-	NO	042H1104
	-	35	YES	042H1105
	-	35	NO	042H1106
	-	42	YES	042H1107
	-	42	NO	042H1108
EVR 40	1 5/8	-	YES	042H1109
	1 5/8	-	NO	042H1110
	2 1/8	-	YES	042H1111
	2 1/8	-	NO	042H1112
	-	42	YES	042H1113
	-	42	NO	042H1114

EVR flare connection, Normally Closed (NC) - separate valve bodies

Type	Connection Size (Inch)	Connection Size (mm)	Manual Operation	Code No
EVR 2	1/4	6	NO	032F8056
EVR 3	1/4	6	NO	032F8107
EVR 3	3/8	10	NO	032F8116
EVR 6	3/8	10	NO	032F8072
EVR 6	1/2	12	NO	032F8079
EVR 10	1/2	12	NO	032F8095
EVR 10	5/8	16	NO	032F8098
EVR 15	5/8	16	NO	032F8101
EVR 15	5/8	16	YES	032F8100
