4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A

4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A

  • 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A
  • 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A
4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: None
Model Number: 4TB-4U
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: Negotiation
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: 4 Way Reversing Valve D Port Size: 8.1mm (5/16'')
E.S.C Port Size: 9.6mm (3/8'') Power: 0.75 To 1.5HP
Applicable Refrigerant: R22, R407C, R410A, Etc Application: Heat Pump, Air Conditioning, Etc
Voltage: 24VDC, 24VAC, 110VAC, 220VAC
Highlight:

Four-way Reversing Valve for Air Conditioning Refrigeration

,

Four Way Reversing Valve Refrigeration

,

4-Way Reversing Valve for Heat Pump

4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A


The 4 way reversing valves are used in reversible applications such as heat pumps or reversible air conditioning units and chillers. The 4 way reversing valve allows an inversion of the refrigeration cycle, changing from cooling mode in Summer to heating mode in Winter.


Technical Data:

4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 0
Model No
Orifice Size
(mm)
Port Size
(mm)
Operating Pressure Difference (MPa)
Internal Leakage (ml/min)
P=1MPa at 70℃
Power
(HP)
D
E.S.C
Min
Max
4TB-4U
8
8.1
9.6
0.25
2.5
＜1000
0.75 to 1.5
4TB-9U
11
9.6
12.8
0.34
2.25
＜1500
2 to 3
4TB-11
11.5
12.8
16
0.34
2.25
＜2000
2.5 to 4
4TB-11U
11.5
9.6
16
0.34
2.25
＜2000
2.5 to 4
4TB-20
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-20U
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-34
20
19.05
22.2
0.34
2.25
＜6000
7.5 to 12
4TB-45
23
22.2
28.5
0.34
2.76
＜6000
5 to 15
25.6
28.5
34.9
0.34
2.76
＜6000
5 to 20


Working Principle:

4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 1


Structure:

4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 2


Our Production:
4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 3

Related Products

4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 4 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 5 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 6 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 7
Solenoid Valve Expansion Valve Hot Gas Bypass Valve Pressure Regulator
4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 8 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 9 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 10 4TB-4U Four-way Reversing Valve for Air Conditioning Refrigeration With R22 R407C R404A R410A 11
Ball Valve Check Valve Sight Glass Access Valve


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
