Name: SEISHIN Type SK-80 Air Knocker SK series SK80 Pneumatic Hammer
Brand: Ningbo Brando Hardware Co., Ltd
SKU: K25
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Hose Fittings

SEISHIN Type SK-80 Air Knocker SK series SK80 Pneumatic Hammer

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	K25

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Pneumatic Air Knocker	Inlet Size:	3/8''
Exhaust Size:	3/8''	Body Material:	Aluminum Alloy
Operating Pressure:	0.3 To 0.7 MPa	Air Consumption:	0.455 L/Time
Impact Force:	19.3 To 29.5 Kgm/s	Net Weight:	7.6kg
Highlight:	SK Series Pneumatic Air Knocker , SK-Air Knocker , SEISHIN SK-80 Air Knocker

SEISHIN Type SK-80 Air Knocker SK series SK80 Pneumatic Hammer

This is SK-80 air knocker similar to SEISHIN. Pneumatic air knocker keeps on hammering without a break to remove powder clogging and adhesion in hoppers and pipes, which are popularly used for many applications in fields such as manufacturing, food processing and pharmaceuticals.

Technical Data:

Model No	Working Pressure (bar)	Air Consumption (L/Time)	Wallop (kgm/sec)
SK-30	3 to 7	0.028	~0.75
SK-40	3 to 7	0.082	~2.2
SK-60	3 to 7	0.228	~7.4
SK-80	4 to 5	0.455	~16.4
SK-100	5 to 7	1.012	~30.0

Main Dimension:

SEISHIN Type SK-80 Air Knocker SK series SK80 Pneumatic Hammer 0

Model No	A	B	C	D	E	G	H	L	S	T	Y	R
SK-30	75	10	82	13	9	1/8''	132	68	6	50	27	1/4''
SK-40	90	12	97	18	11	1/4''	162	78	10	60	34	1/4''
SK-60	121	13	143	19	15	1/4''	215	100	10	60	48	1/4''
SK-80	160	17	170	20	17	3/8''	260	140	14	90	70	3/8''
SK-100	200.	18	200	23	17	3/8''	318	160	18	90	70	3/8''

Installation Examples:

SEISHIN Type SK-80 Air Knocker SK series SK80 Pneumatic Hammer 1

Our Production:

SEISHIN Type SK-80 Air Knocker SK series SK80 Pneumatic Hammer 2

Related Products:


Pneumatic Fitting	Pneumatic Silencer

Similar Products:


Pneumatic Ball Vibrator	Pneumatic Turbine Vibrator	Pneumatic Roller Vibrator

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
