2S040-10 3/8'' Stainless Steel Electric Solenoid Valve 24V 110V 220V
This is a 2S040-10 mini solenoid valve, 3/8 inch (G, NPT) female thread port size, stainless steel 304 body material, NBR seal material, 2 way normally closed, direct acting, 12V DC, 24V DC, 110V AC, 120V AC, 220V AC, 230V AC voltages for you to choose, other voltages can be customized.
2W series brass solenoid valve: 2W025-06, 2W025-08, 2W040-10, 2W160-10, 2W160-15, 2W200-20, 2W250-25, 2W350-35, 2W400-40, 2W500-50.
Technical Data of 2W & 2S Solenoid Valve:
2W Series
2W025-08
2W040-10
2W160-15
2W200-20
2W250-25
2W350-35
2W400-40
2W500-50
2S Series
2S025-08
2S040-10
2S160-15
2S200-20
2S250-25
2S350-35
2S400-40
2S500-50
Orifice Size
2.5
4
15
20
25
35
40
50
Port Size
1/4''
3/8''
1/2''
3/4''
1''
1-1/4''
1-1/2''
2''
Medium
Water, Air, Gas, Oil
Action
Direct Acting
Semi-Direct Diaphragm Operated
Function
2 Way, Normally Closed
Fluid Viscosity
20 CST below
0 to 1.0 Mpa
Temp. Range
-5 to +85℃
Main dimension of 2W & 2S Series Solenoid Valves:
Deconstruction diagram of Stainless steel body electric water valves:
Brando Factory Production of Solenoid Valves: VIDEO
More Stainless Steel Solenoid Valves for you to choose:
