Name: 2S200-20 3/4'' 2/2 Way Norally Closed Water Stainless Steel Solenoid Valve
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 2S200-20
Price: 26.00 USD
Availability: InStock

Home Products Stainless Steel Solenoid Valve

2S200-20 3/4'' 2/2 Way Norally Closed Water Stainless Steel Solenoid Valve

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	2S200-20

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Valve Series:	2S Series	Ref. Number:	UNI-D Type SUW-20
Voltage:	AC110V AV220V DC24V	Action:	Pilot Diaphragm
Port Size:	3/4'' Inch	Media:	Water Air Gas
Body Material:	Stainless Steel	Diaphragm Material:	NBR, FKM And EPDM
Highlight:	Solenoid Valves Air Valves 2S200-20 , Fluid Control Valve 2S200-20 , 2S200-20 2 WAY SOLENOIDS

2S200-20 3/4'' 2/2 Way Norally Closed Water Stainless Steel Solenoid Valve

2S200-20 is an electromagnetic valve, stainless steel, appropriate is used in the field of circulation time longer control, adopting direct acting diaphragm structure, the body is made of stainless steel, corrosion resistant function.It adopts a diaphragm structure and has the characteristics of quick opening and closing, stable performance, convenient use, high reliability and long service life. The water-using solenoid valve has strong anti-pollution ability. It can be used for a long time in rivers, rivers, lakes, oceans and various artificial waters.

Technical Data of 2W & 2S Solenoid Valve:

2W Series	2W025-08	2W040-10	2W160-15	2W200-20	2W250-25	2W350-35	2W400-40	2W500-50
2S Series	2S025-08	2S040-10	2S160-15	2S200-20	2S250-25	2S350-35	2S400-40	2S500-50
Orifice Size	2.5	4	15	20	25	35	40	50
Port Size	1/4''	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Water, Air, Gas, Oil
Action	Direct Acting		Semi-Direct Diaphragm Operated
Function	2 Way, Normally Closed
Fluid Viscosity	20 CST below
Pressure Range	0 to 1.0 Mpa
Temp. Range	-5 to +85℃

Main dimension of 2W & 2S Series Solenoid Valves:
2S200-20 3/4'' 2/2 Way Norally Closed Water Stainless Steel Solenoid Valve 0

2S Series	2W Series	A	B	C	D	E
2S025-06	2W025-06	64.5	30	75	43	1/8''
2S025-08	2W025-08	64.5	30	75	43	1/4''
2S040-10	2W040-10	70.6	32	82.4	53	3/8''
2S160-10	2W160-10	101.5	57	117	69	3/8''
2S160-15	2W160-15	101.5	57	117	69	1/2''
2S200-20	2W200-20	107	57	123.5	73	3/4''
2S250-25	2W250-25	111.5	73.5	134.5	99	1''
2S350-35	2W350-35	142	95	172	123	1-1/4''
2S400-40	2W400-40	142	95	172	123	1-1/2''
2S500-50	2W500-50	172	123	209	168	2''

Deconstruction diagram of Stainless steel body electric water valves:

2S200-20 3/4'' 2/2 Way Norally Closed Water Stainless Steel Solenoid Valve 1

Brando Factory Production of Solenoid Valves:

More Stainless Steel Solenoid Valves for you to choose:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
