Name: Turbo Type GPC10 Pilot Armature Plunger For Pulse Valve Assembly Replacement
Brand: Ningbo Brando Hardware Co., Ltd
SKU: BAPC210028603
Price: 49.10 USD
Availability: InStock

Home Products Solenoid Valve Armature

Turbo Type GPC10 Pilot Armature Plunger For Pulse Valve Assembly Replacement

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	None
Model Number:	BAPC210028603

Payment & Shipping Terms:

Minimum Order Quantity:	200
Price:	Negotiation
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	Negotiation
Payment Terms:	T/T,PayPal,Western Union
Supply Ability:	300000sets per month

Contact Now

Detailed Product Description

Product Name:	Pulse Valve Armature	Ordering Code:	GPC10
Plunger Tube Material:	Stainless Steel	Seal Material:	NBR, VITON
Fitted Pulse Valve Model:	FP20, FP25, DP20, DP25, EP25, SQP20, SQP25, FDP20, FDP25, FP40, DP40, EP40, FP50, FP55, SQP50, SQP55, SQP60, SQP65, FP65, SQP75	1 Set:	1pc Plunger Tube, 1pc Iron Core, 1pc Spring
Highlight:	GPC10 Assembly Replacement , GPC10 Assembly Kit For Turbo , Turbo GPC10

Turbo Type GPC10 Pilot Armature Plunger For Pulse Valve Assembly Replacement

This is GPC10 solenoid armature for Turbo Pulse Jet Valve FP20, FP25, DP20, DP25, EP25, SQP20, SQP25, FDP20, FDP25, FP40, DP40, EP40, FP50, FP55, SQP50, SQP55, SQP60, SQP65, FP65, SQP75.

Electromagnetic pulse valve, also called diaphragm valve acts as a "switch" for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.

Dimension & Data of Armature, Coil for Turbo Pulse Valve:

BRANDO Model	BAPC210029002
Ordeirng Code	GPC 10
Plunger Tube Material	Stainless Steel
Seal Material	NBR, VITON

Turbo Type GPC10 Pilot Armature Plunger For Pulse Valve Assembly Replacement 1

BRANDO Model	BB10230001
Ordering Code	BH10
Voltage	24VDC, 110VAC, 220VAC (50/60Hz)
Power	10VA, 19VA, 6W, 15W
Connector	DIN 43650 Form A
Insulation Class	F, H

Video of Solenoid Armature For Turbo Pulse Valve:

BRANDO Solenoid Valve Armature Production Video:

More Turbo Type Pulse Jet Valve for you to choose:


Threaded Type	Submerged Type	Valve Diaphragm

Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
